Automatic High Speed Cardboard Corrugated Board Foil Stamping & Die Cutting Die Cutter Machine
- Category: >>>
- Supplier: Shanghai Asianray Industry Development Co. Ltd.
Share on (62043336152):
Product Overview
Description
Product Description
Auto pressure adjustment system by servo motor, higher precision and more convenient. Automatic decreasing pressure if no paper, extend mould service life. Non-stop sampling function, improve work efficiency.
| Max. sheet size | 800×620mm |
| Min. sheet size | 360×290mm |
| Max. die cutting size | 790×610mm |
| Inner chase size | 880×628mm |
| Max. working speed | 8000s/h |
| Max. stamping speed | 6500s/h |
| Paper range | 90-2000g/m2 |
| Foil pulling shafts | longitudinal 3, transversal 2 |
| Max. foil diameter | 220mm |
| Zones individually heated | 10 zones (each zone can be adjusted independently, max 200℃) |
| Cutting accuracy | ±0.1mm |
| Max. working pressure | 200T |
| Gripper margin | 8-17mm |
| Max. feeding pile height | 1280mm |
| Max. delivery pile height | 1070mm |
| Main motor power | 7.5kw |
| Total machine power | 38kw |
| Air requirements | 0.6Mpa, >0.37m3/min |
| Machine weight | 17T |
| Overall machine dimensions | 5380×3935×2445mm |
