Bardiche CUT63G CUT Machine Plasma Cutting Manufacturing Plant,construction Works 14A@63A Stepper Motor United States 21.7KG
- Category: CNC Plasma Cutters >>>
- Supplier: Wenzhou Chiefstone C&T Co. Ltd. [Zhejiang China]Wenzhou Ltd.
Share on (62043537686):
Product Overview
Description
Product description
Processes:
CUT
CNC
Package Includes:
Inverter power source
Cut torch, 5m
Earth Clamp, 3m
Air filter
Hose, 3m
Features:
Able to connect to CNC automatic equipment.
Qaulity cut up to 10/15mm thickness carbon steel, max cut up tp 16/25mm thickness carbon steel.
2T/4T
Gas Purge
Gas Pressure Meter
Post-flow adjustable
Easy Arc Ignition with high Frequency
Smooth and neat cutting surface.
Tri-proof air duct design.
Technical Data:
Model | CUT63G | CUT80GT |
input voltage/phase /frequency | 380V/3P/50-60HZ | 380V/3P/50-60HZ |
output current/voltage/duty cycle | 63A/105V/60%@40°C 46A/98.4V/100%@40°C | 80A/112V/60%@40°C 46A/98.4V/100%@40°C |
amps input rated output | 14A@60A | 17.6A@80A |
Output range/ocv | 23-63A/300V | 20-80A/300V |
Dimension | 508x244x423 mm | 508x244x423 mm |
Weight | 21.7 kg | 21.7 kg |
