10TON Commercial Use Anti corrosion Copper Fins Rooftop Packaged Unit Customized Central Air Conditioner Good Price

Product Overview

Description

With the development of economy, all walks of life have higher and higher technological requirements, and the use of central air conditioners has become wider and wider. It has continuously entered various special environments, such as marine air conditioners corroded by salt spray and tobacco corroded by nicotine. Air conditioners, underground air conditioners in high humidity environments, chemical air conditioners corroded by chemical gases, etc. Central air conditioners in these special environments have different levels of anti-corrosion requirements. For different parts, the anti-corrosion measures of central air conditioning can be divided into three methods: epoxy resin spraying, electrophoresis, and material replacement (copper tube aluminum fins are replaced with copper tube copper fins.

10TON Marine Rooftop Packaged Unit Use Anti-corrosion Copper Fins

Specifications:

Hermetic scroll compressor

Cooling capacity:13~255kw

Cooling only, electric heating, heat pump type

High static pressure duct type

R22, R407C.



Features:

1) Applied to dry areas;Marine,ship,boat,vessels.

2) Compact structure, installed on the roof, convenient for installation, occupy no indoor space ;

3) Sufficient external static pressure, suitable for connecting air duct system, reduce indoor noise greatly;

4) Different series of products, meet different requirements;

5) The framework of units is anti-cold bridge aluminum alloy, which eliminates cooling leakage and condensate water due to large temperature difference between inside and outside.

6) The main parts are imported quality products, with excellent performance;

7) The evaporator and condenser adopts technology of enhancing heat transfer, which makes the exchanger high efficiency and save energy.

WKL Series Air Cooled Cooling TypeRooftop Air Conditioners
Model Type				WKL36
System Characters	Cooling Capacity		KW	97.5
	Electric Heating Capacity		KW	54
	Air Volume		m3/h	19200
	External Static Pressure		Pa	400	550
	Noise Level		dB(A)	76	78
	Temperature Range and Accuracy			18℃~30℃±1℃
	Power Supply			3N~50HZ 380-400V
	Total Power	Cooling	KW	37.5	37.5
		Heating	KW	56	56
Refrigerating System	Refrigerant	Type		R22
		Way of Throttling		Outside Balanced Thermal Expansion Valve
	Compressor	Type		Hermetic Scroll Compressor
		Power	KW	9×3
	Evaporator	Type		Tube with Fins
		Fin Type		Slotted-type Two-way Aluminum Fins
	Condenser	Type		Tube with Fins
		Fin Type		Corrugated Aluminum Fins
Air Sending System	Condenser Fan	Type		Ultra-low-noise Axial Type
		Drive Method		Direct-drive
		Motor Power	KW	1.5×2
	Evaporator Fan	Type		Ultra-low-noise Double-inlet Centrifugal Type
		Drive Method		Belt Transmition
		Motor Power	KW	5.5	7.5
Heater		Type		Electric Heating
		Power	KW	54
Air Filter				Nylon Bump Net
Dimensions		Length	mm	4000
		Width	mm	1600
		Height	mm	2160
Weight			kg	2160
MOQ			units	1
Delivery Time			days	35
