20W Solar Camera Use Photovoltaic Panel In Solar Cell 6X6 For Led Lightings And Battery Packs

Product Overview

Description



Tempered glass can withstand high impact force

High surface transmittance, effective resistance to hail

Anode aluminum alloy frame, 25 years will not oxidize

Anti - aging back plate, waterproof seal

Humanized design installation hole, simple and convenient installation



Physical Parameter
Model	MAX-M20W
Size:	360*510*20mm
Weight:	2kg
Number of cells:	36pcs
Type of cells:	Poly
The surface of glass:	Tempered glass
Connnector type:	SAE
The connection method:	Series and Parallel connection
Electrical Performance Parameter
Peak power: 20W	Working voltage: 18(V)
Working current(IMP): 1.11(A)	Open-circuit voltage: 22.45(V)
Short-circuit current(ISC): 1.17(A)	Thermal endurance: -40℃ to +80℃
Number of diodes: 1
Test standard (environment): irradiance 1000 w/sq.m, environment temperature 25 ℃, AM = 1.5
