5w/10w/16w/18w/25w/34w Copper Aluminum Wire Shaded Pole Motor
- Category: >>>
- Supplier: Xi Maike (guangdong) Refrigeration Technology Co. Ltd.
Share on (62047471398):
Product Overview
Description
Product Description
We can supply Refrigeration Elco Type Fan Motor,shaded pole motor for radiators/evaporators,fan motor,motor,electric fan motor,electric motor..
YZ series motors are shaded pole motors with single-phrase and four-pole, and running
at the rated voltage/frequency of 220-240v, 50/60HZ or 110-120v, 60HZ. They are widely applied to radiators, evaporators and other refrigeration equipments.
1)4 shaded poles,single phase ,alternating current.
2)output power:5W, 6W,7W, 10W,12W,16W, 18W, 25W, 34W
3)Running at rated voltage of 220-240V,50/60HZ or 110-120V,60HZ
4) Insulation class of motors is B with the protection class IP42.
IP44 is also available.
6) Applicable ambient temperature is -30degree to 50 degree
7) Average service life is over 20000 hours
8) CE,VDE,UL, RoHs& CCC certificates be attained
9)Accessories need or not is up to you.
| Shaded Pole Motor 5W/10W/16W/18W/25W/34W | |||||
| Model | Voltage(V) | Frequency (Hz) | Current (A) | Input/Output (W) | Speed (rmp) |
| 5W | 220V | 50/60Hz | 0.2 | 5-25W | 1300/min |
| 10W | 220V | 50/60Hz | 0.25 | 10-40W | 1300/min |
| 16W | 220V | 50/60Hz | 0.45 | 16-60W | 1300/min |
| 18W | 220V | 50/60Hz | 0.5 | 18-70W | 1300/min |
| 25W | 220V | 50/60Hz | 0.7 | 25-90W | 1300/min |
| 34W | 220V | 50/60Hz | 0.85 | 34-110W | 1300/min |
| They are widely used in radiators,evaporators and other refrigeration equipment. | |||||
Specification
products of picture
Company Information
Exhibition
FAQ
Q1: Are you a factory or a trading company?
A1: We have a factory
Q2: Where is your factory located?
A2: Our factory is located in Guangzhou, Guangdong province.
Q3: Is a sample available?
A3: Yes, but the sample will be at your charge.
Q4: What is the main market for your products?
A4: Our main market is in Middle East, Palestine, Turk, Africa and so on.
A1: We have a factory
Q2: Where is your factory located?
A2: Our factory is located in Guangzhou, Guangdong province.
Q3: Is a sample available?
A3: Yes, but the sample will be at your charge.
Q4: What is the main market for your products?
A4: Our main market is in Middle East, Palestine, Turk, Africa and so on.
Welcome to contact us for more details!
