XH2418 double column machining centercncgantrymilling machine
- Category: >>>
- Supplier: Tengzhou XILI Machine Tool Co. LTD.
Share on (62047707163):
Product Overview
Description
XH2418 double column machining center cnc gantry milling machine
Specification | Unit | XH2418 | XH2420 | XH2425 |
Table travel X | mm | 2600/3100/4100 | 3200/4200/6200 | 4200/6200/8200 |
Table travel Y | mm | 2400 | 2650 | 3400 |
Table travel Z | mm | 1000 | 1000 | 1200 |
Table size | mm | 2500/3000/4000*1800 (3200*1800) | 3000/4000/6000*2000 | 4000/6000/8000*2500 |
Distance between columns | mm | 2200 | 2500 | 3200 |
Max table load | Kg | 9000/12000 | 10000/15000/20000 | 22000/30000/38000 |
T-slot (N/W/D) |
| 9/28/180 | 9/28/200 | 11/28/200 |
Feeding speed XYZ | mm/min | 1-8000 | ||
Rapid feed speed XYZ | m/min | 12/12/10 | ||
Distance between spindle and table surface | mm | 250-1250 | ||
Spindle taper | / | BT50 | ||
Power of spindle motor | Kw | 22 | ||
Spindle speed range | rpm | 6000 | ||
Positioning accuracy | mm | ±0.005/300 | ||
Repeatability | mm | ±0.003/1000 | ||
Overall size | mm | 7000/8000/11000*4800*3800 | 8000/10000/14000*5100*4800 | 10000/14000/18000*5900*5000 |
Net weight | t | 27/33/40 | 38/42/52 | 55/85/105 |
XH2418 double column machining center cnc gantry milling machine
has a wide application in various production like plate, box , framework......., rough & finish machining, various procedures like milling, boring, drilling, rigid tapping, reaming and countersink machining of machining industry.
XH2418 double column machining center cnc gantry milling machine
X, Y, Z axis servo control, direct coupled structure is adopted in the Taiwan high precision and high intensity of ball screw, screw installation of pre stretching, connecting rigidity, high feed speed; the servo motor directly transferring power to a high precision ball screw, no backlash, ensure the machine tool positioning accuracy. The Z shaft is provided with a hydraulic balancing device, which ensures.
XH2418 double column machining center cnc gantry milling machine
CNC system (FANUC, Mitsubishi, Siemens, wide number) can be selected. The system has perfect and reliable interlocking, safety protection and fault diagnosis and alarm functions, equipped with RS232 communication interface;
FAQ
1. What is your minimum order quantity and warranty?
MOQ is one set, and warranty is one year.
2.What CNC system do you use?
FANUC, SIEMENS, MISTSUBISHI, GSK etc. It depends on your choice.
3.When is the delivery time?
We will delivery it within 60 days after received your payments
4. How to handle the warranty period?
During the warranty period, because of product quality problems, the company is responsible for free maintenance, if need to change parts, we be responsible for free replacement.
If the machine problem is not belonging to our machine quality problems, when the buyer needs us send engineers to give repairing service, we charge the appropriate cost.
5.Can your company send the technical personnel to our company and direct our workers for free?
When the machine arrive the buyer’s installation site, we timely send mechanical and electrical engineers to install according to the buyer's schedule, the buyer undertakes board and lodging of personnel abroad in the process of installation, and also USD50.00-100.00 per day per person. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
6.What's the trade assurance?
When you look at our alibaba website, you will see the trade security, its purpose is to let every buyer confidence, it can protect your payment, ensure that the suppliers fulfill their commitment to the date of shipment and the quality of the products (as you stated in the purchase order).
7.Do your products support trade assurance?
Yes, our products are all supported.
Company Information
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. are special on milling machine and CNC drilling machine We have more than 30 years manufacturer experience. All our products passed CE, ISO9001. We also do OEM for Germany Knuth, Optimum, Austria Bernado and so on. You can trust our quality and service.
Hope we can build long-term business relationship with you.
