RocketRAID 3740C 16 Ports 12Gb/s PCIe 3.0 x8 SAS/SATA RAID Host Bus Adapter

Product Overview

Description

RocketRAID 3740A RR3740A 16 Ports 12Gb/s PCIe 3.0 x8 SAS/SATA RAID Host Bus Adapter



RocketRAID 3700 series host bus adapters capitalize on HighPoint’s two decades of RAID and storage technology to deliver professional grade RAID storage at a fraction of the cost of conventional host RAID solutions. Each adapter is powered by our industry proven RAID technology, superior Gen 3.0 PCIe express transfer bandwidth, and up to sixteen dedicated 12Gb/s SAS channels, which support robust, high-performance RAID 0, 1, 5, 6, 1/0, 5/0 and JBOD configurations of SAS or SATA hard drives of any disk format, including 512, 512e and 4Kn.
RocketRAID 3700 series host bus adapters are designed to maximize the uptime and accessibility of RAID storage. RocketRAID storage and RAID recovery solutions enhance data retrieval from failed disks and streamline rebuild sessions.
The universal RocketRAID WebGUI interface provides a wide range of preemptive monitoring and maintenance features that enable administrators to easily schedule verification sessions to ensure the health of each RAID storage configuration.



Specifications



Bus Interface	8-lane, 8 GT/s PCI Express 3.0 Compliant
Number of Channel / Port	16 x 12Gb/s SAS/6Gb/s SATA Channels
Data Transfer Rates	Up to 12Gb/s per port
Port Type	4 x SFF-8643 mini-SAS HD
Storage Device Support	16 x SAS/SATA Hard Drive/SSD
Form Factor	Low Profile
Dimensions	5.97*2.68*0.06 (in)
RAID Level Support	0, 1, 5, 6, 1/0, 5/0 and JBOD / Non-RAID Mode
	RAID 6 is not supported on macOS.
	Bootable RAID 6 arrays are not supported.
	RAID 1/0 is the equivalent of RAID 10. RAID 5/0 is the equivalent of RAID 50.
Operating System Support	Window Server 2008 and Window 7 and later
	Linux
	macOS
Flash ROM for Upgradeable BIOS	Yes
Storage Health Inspector	Yes
Redundant RAID Configurations	Yes
BIOS PnP (plug and play) and BBS (BIOS boot specification) support	Yes
Bootable RAID Array	Yes
EFI for Mac Platform	Yes
Multiple RAID Partitions supported	Yes
Storage Configurations	Direct Attached
Multiple RAID Adapters supported	Yes
Online Array Roaming	Yes
Online RAID Level Migration (ORLM)	Yes
Online Capacity Expansion (OCE)	Yes
RAID Quick Initialization for fast array setup	Yes
Drive hot-plug support	Yes
Global Hot Spare Disk support	Yes
Automatic and configurable RAID Rebuilding Priority	Yes
Auto resume incomplete rebuilding after power on or reboot system	Yes
Disk Format compatible:	Yes
512, 512e, 4Kn
Larger than 2 TB Drive and RAID Array support	Yes
Spin down Massive Arrays of Idle Disks support	Yes
Native Command Queuing	Yes
SAS TCQ	Yes
Disk media scan and repair	Yes
Device Error Recovery support	Yes
Automatic remap and fix drive bad block for RAID array	Redundant RAID Levels (RAID 1, 5, 6, 1/0, 5/0)
Staggered Drive Spin Up	Yes
Write Back and Write Through	Yes
