Chile Hot Selling Euro V FOTON 8x4 Cargo Lorry Truck With 14T 16T Folding Crane

This Foton Auman 8x4 crane truck, with Euro-5 cum-mins 300hp diesel engine, can load 25-30 ton cargo, can match 14 ton or 16 ton crane, straight crane or folding arm crane for choose.
Truck mounted crane is also called truck with crane, cargo truck with crane, flatbed truck with crane, lorry truck mounted crane, telescopic boom truck, telescopic truck mounted crane, crane truck, etc.
1. Optional crane truck brands: Dongfeng, SINOTRUK, HOWO, JAC, JMC, Foton, Forland, Hino, Iveco, YUEJIN, Isu zu, FAW, Shacman, Beiben, etc.
2. Driving type: 4x2, 4x4, 6x4, 6x6, 8x4 truck with crane, left hand drive or right hand drive.
3. Crane type: Straight / folding arm telescopic crane, 360-degree full rotation.
4. Optional crane capacity: 1 ton, 2 ton, 3.2 ton, 4 ton, 5 ton, 6.3 ton, 8 ton, 10 ton, 12 ton, 14 ton, 16 ton, 25 ton.
Specifications of FOTON 8x4 Cargo Lorry Truck With 14T 16T Folding Crane:
Item | unit | parameter | ||
Vehicle model |
| Foton Auman 8x4 truck with crane | ||
Chassis model |
| BJ5312JSQ-AA | ||
Overall dimensions | mm | 12000×2500×3860 | ||
| Fact loading | kg | 25000-30000 | |
Mass in working order | kg | Appro×19085 | ||
Body internal dimensions | mm | 8300×2400×550 | ||
Wheel base | 2100+4500+1350 | |||
F/R track base | 1960/1960/1860/1860 | |||
Approach/departure angle | ° | 18/8.5 | ||
Exhaust/kw | ml/kw | 10500/220 | ||
Max speed | km/h | 90 | ||
Tire specification | 11.00R20 | Engine type | ISGe5-300 (Euro V) | |
Traction system | 8×4 | transmission | 9-speed with over drive | |
Number of axles | 4 | Electric system | 24v | |
Operation control system | Electrically hydraulic control | Allowable passengers in cab | 3 | |
Equipment | Crane Type: 14T or 16T straight or folding telescopic crane Hydraulic valve is universal in the world on the safe side; three point floating type to protect crossbeam of the truck; all hydraulic pressure and 360°turning;new H-shape type; high precise drawn tube;24°tie-in. With high-altitude operating seat, hydraulic double-chamber rear leg | |||
Engine | Beijin Foton Cummins diesel engine 300 hp | |||
Production cycle | 20-25 working days | |||
Warranty | 12 month, from the date of supply | |||
FOB Shanghai | USD | |||







1> Packaging: Nude,but waxed before shipment in our factory.
2> Shipping: Small type can be put into 20' or 40' container, big type must be shipped by bulk carriers or ro-ro ship or according to your requirements.

1. We are the biggest professional special trucks manufacturer in China,being in this field for 10 years.
2. We can supply more than 300 kinds of special trucks for your needing.
3. OEM Sevice: we can produce the trucks according to your request,such as the material,the size,the colour and the logo is optional for you.
1> Our company has solid technology, flawless inspection, advanced equipment, reliant quality and flexible modes operation.
2> We have roundly passed the certification of ISO9001-2008, the 3C (China Compulsory Certification) and other certifications that export needed.
3> We have more than 2000 workers and factory is more than 690,000m2, we have successfully exported to Ghana, Sudan, Kuwait,Nigeria, Angola ,Tajikistan, Azerbaijan,Namibia, Burma, Korea, Iran, Afghanistan,Iraq, Philippines ,Vietnam , Saudi Arabia ,Mexico,Chile ,Bolivia etc. more than 5000 trucks to many Africa & Asia countries.
4> We can produce 12,000 trucks every year, our brand "CLW" obtain "the Chinese well-known trademark".
5> We cooperate with famous chassis manufacturers, such as DONGFENG, FAW, FOTON, JMC, JAC, and NAVECO, etc.
Welcome to visit ChengLi Special Automobile Co.,Ltd !
