LCD led advertising display screen for restaurant
- Category: >>>
- Supplier: Shenzhen Cta Display Technology Co. Limited
Share on (62049773004):
Product Overview
Description
Hot sale totem lcd digital signage advertising display
Hot sale totem
LCD led advertising display screen for restraunt
Product Description
Product Description for LCD led advertising display screen for restraunt
| Specifications | ||||||||||
| Model No. | CTA-AD5531 | |||||||||
| Panel size | 10-98" TFT-LCD | |||||||||
| Display area(mm)/mode | 680.4(W)x1209.6(H) 9:16 | |||||||||
| Maximum resolution | 1920*1080 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.4845(H)×0.4845(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 3000:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 5ms | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Touch Panel | ||||||||||
| Specification | Infrared Touch/Capacitive Touch | |||||||||
| positioning accuracy | ±2mm | |||||||||
| Touch Media | Finger/touch pen opaque objects | |||||||||
| Transmittance | ≥92% | |||||||||
| Glass Hardness | 7H | |||||||||
| Click Mode | 2/4/6/8/10 points/multipoint(optional) | |||||||||
| Response Time | ≤5ms | |||||||||
| ClickLife Time | >=60M times | |||||||||
| PC /Android | ||||||||||
| Motherboard | H61/H81 | |||||||||
| CPU | I3/I5/I7 | |||||||||
| Memory | DDR3 1333MHZ 4GB/8GB | |||||||||
| Hardware | SATA II320GB/500GB | |||||||||
| Keyboard and Mouse(Optional) | wireless waterproof keyboard and mouse set | |||||||||
| Interface | USB*4,VGA*1,DVI*1,HD*1,RJ45*1,Audio*1,MIC*1 | |||||||||
| Software environment | Windows XP/ Windows 7/ Windows 10 /Linux | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( Multiple Language Supported) | |||||||||
| Power | ||||||||||
| Power supply | 100-240V AC 12V/ DC | |||||||||
| Maximum power consumption | 230W | |||||||||
| Standby power consumption | <3W | |||||||||
| Temperature | ||||||||||
| Working temperature | -20°C~+80°C | |||||||||
| Storage temperature | -40°C~+80°C | |||||||||
| Working humidity | 25%~85% | |||||||||
| Storage humidity | 20%~90% | |||||||||
| Support signal format | ||||||||||
| Video format | MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI | |||||||||
| Audio format | Wave/MP3/WMA/AAC | |||||||||
| Image format | JPEG/BMP/TIFF/PNG/GIF | |||||||||
| Image resolution | 480P/720P/1080P | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 1000*500.*1300.2 ((for reference) | |||||||||
| Panel color/appearance | White, black, customized | |||||||||
| Panel material | Metal case SPCC | |||||||||
| Installation | Floor-standing | |||||||||
| Warranty | 1 year | |||||||||
More Products Maybe More Attractive To You
Click Below Pictures Learn More Detail
 |  |  |
 |  |  |
 |  |  |
All of our products can be customized. Any sizes, material, designs, logos meet your requirement,before quote you the price ,we will be appreciated if you can provide the information below:
ü lcd advertising display screen logo
ü lcd advertising display screen design
ü lcd advertising display screen color
ü lcd advertising display screen size
ü lcd advertising display screen material
ü lcd advertising display screen function
ü If possible ,please supply us the picture or design of the lcd advertising display screen.
If you are not clearly , we will recommend for you.
Company Information
Packaging & Shipping
1. Packing in carton and wooden frame ,wooden case and flight case.
2. As customer demand.
3. Shipping port: Shenzhen, Guangzhou etc.
4. Shipping: by sea, by air and by express delivery.
2. As customer demand.
3. Shipping port: Shenzhen, Guangzhou etc.
4. Shipping: by sea, by air and by express delivery.
