water oil fuel diesel Double superlink interlink Tank drawbar Trailer for sale (carbon steel aluminum stainless steel)

Double Tanker Semi Trailer

Axle No.

Axle Location

Tire No.

Length

Rating Capacity

1

Rear

4

4000-7500mm

15Tons

2

1+1

8

7500-12500mm

40Tons

3

1+2

12

12500-15000mm

60Tons

4

2+2

16

15000-18000mm

80Tons

Suspension

America type mechanical Suspension

Wheel

11:00 R20

Turntable

Diameter is 1100mm

Traction hook

DN50

Traction bar

Length is 1.4m

Dimensions(LxWxH)

7500-18000×2500×1500mm

Steel Spring

10/10 pieces per axles

Tire:

The material of
Main beam

The height of the beam is420mm,upper plate is 12mm*140,down plate is 12*140mm,middle plate is 6mm(strictly).made of Q345

Platform plate

3mm Diamond Plate

Brake:

WABCO VALVE

Brake

Kemi Brand of China

Brake Chamber

TWO double and two single chamber( TKL brand  )

ABS system

with

Electrical:

Voltage

24V

Receptacle

7 ways(7 wire harness)

Light color:

(LED light)

Side marker lamp

Orange

Rear lamp

Red

Turn signal lamp

Orange

Miscellaneous:

Painting

Can be choose freely

Marking

According to the requirement of the buyer

Side Guard

According to the requirement of the buyer

Tools box

One pieces or According to the buyer(1m length)

 Water tank

The size can be choose freely.
