polymer dosing machine /powder dosing machine /automatic chlorine dosing system

Product Overview

Description

polymer dosing machine /powder dosing machine /automatic chlorine dosing system





polymer dosing machine /powder dosing machine /automatic chlorine dosing system developed by Xuridong is well known for the high quality and efficiency

 Product description



1. Easy to operate, labor saving
Precast mixing tank, homogeneous slaking tank and solution storage tank are in one equipment, easy to learn and easy to operate, saving labor.
2. Polymer concentration is adjustable
Water and polymer can get into the tank at the same time, as the flowing rate of the feeding pump can be controlled, so any concentration (within a certain range) can be prepared according to the actual requirements.
3.Well designed machine frame
Precious conveying, delicate pre-soaking device and the constant temperature heating method can reduce agglomeration phenomenon caused by improper operation and prevent the line from clogging, so as to ensure the stable concentration.
4. Trustworthy operation
The unique structure and proper rotating speed of the mixer not only can ensure the homogenization solution, but also will not destroy the polymer molecular chain.
5. Better performance, better environment
First class spare parts to ensure excellent performance, low noise and low vibration.



Technical  assistance

Experienced engineers guidance on line

Experienced engineers guidance live

Mechnical materials

Project design

Technical details

polymer dosing machine /powder dosing machine /automatic chlorine dosing system
Model		YTH500	YTH1000	YTH1500	YTH2000	YTH2500	YTH3000	YTH4000
Preparation of ability(L/h)		500	1000	1500	2000	2500	3000	4000
Power (KW)		1.7	2.45	2.45	2.45	3.5	3.9	3.9
PAM powder feed quantity(kg/h)		1~5	2~10		3~15		3.5~20
Water inflow(m³/h)		03~1.5	0.6~3	0.9~4	1.2~6	1.6~8	2.0~10	2.4~12
External dimension(mm)	L	1370	2000	2130	2200	2400	2400	2720
	B	730	1050	1120	1250	1350	1350	1450
	H	1500	1710	1710	1900	2140	2180	2250
Equipment Net Weight(kg)		380	510	590	710	820	860	1080
Motor Brand		Nord , SEW	Nord , SEW	Nord , SEW	Nord , SEW	Nord , SEW	Nord , SEW	Nord , SEW
Material		Stainless Steel 304	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304	Stainless Steel 304
Operation		Automatic	Automatic	Automatic	Automatic	Automatic	Automatic	Automatic
Dosing capacity		500-4000Lt/hr	500-4001Lt/hr	500-4002Lt/hr	500-4003Lt/hr	500-4004Lt/hr	500-4005Lt/hr	500-4006Lt/hr

     Shandong Xuridong Machinery Co.,Ltd. is a high and new tech enterprise that isconcerned with scientific research and development, production and technology service,All the products are produced completely by us. In 2009, we were certified by ISO9001: 2008. We supply environment consultation, project design,production, construction guidance installation and commissioning, operation management and follow-up service,The polymer dosing machine /powder dosing machine /automatic chlorine dosing system was produced entirely by ourselves absorbs advantages of similar types both at home and abroad







 General international manger:  Mr. Bertram Young

 Tel/whatsapp: +86 15253622917

 Wechat: Y15253622917

 E-mail: yangshengfeng(at)xuridong.com

 Trade manager: Mr. Tom Yang

 Mob: +86 13563631266

 Wechat: xrd13563631266

 Shandong Xuridong Machinery Co.,Ltd

 Add: No.68, Tieyuan road, Zhucheng City, Shandong Province, China

 Tel: +86-536-6081238   Fax: +86-536-6087785   Post code: 262200

  01. Detailed installation manual and maintenance guideline are available

  02. Technical training and site-commissioning are available for you

  03.Any equipment issue,we will stand by

01. How to buy your idea products?

  A: You can provide us your water sources, water quality, flow rate and ground area (connect us for more details).

02. How to pay?

  A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.

03. What is the delivery time?

  A: It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.

 04. How to install after the equipment arriving destination?

  A: We will provide detailed illustrations to you. If necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
