High Quality 4CH 1080P dual sd card mdvr with GPS 4G WiFi optional
- Category: >>>
- Supplier: Dongguan Eastyle Video Technology Co. Ltd.
Share on (62054511110):
Product Overview
Description
Product Description
High Quality 4 channel 1080P dual SD card mobile dvr with GPS 4G WiFi
Features:
Ÿ Built-in high performance Hisilicon chipsets, coded with H.264/H.265 standard, high compression rate and image quality. It can save half of the storage, compared to H.264 compression.
Ÿ AHD/TVI/CVI/IPC/ANALOG five in one video input, wide compliance
Ÿ 4+1 live preview and storage
Ÿ 1CH synchronized AV output, 1CH VGA output
Ÿ Support UPS power input
Ÿ Built-in G-sensor, monitor the driving habits
Ÿ Reverse Assistance
Ÿ Adjust the camera image horizontally and vertically
Ÿ Adjust the camera image 90 degrees
Playback Mobile DVR 1080P HD Image quality
How to playback records:
1. Take out HDD/SD card, connect to PC, then playback or backup records with our MDVRplayer.
2. Backup records to U-Disk from USB port. Then playback or backup on PC.
3. Download records from CMSV6 platform directly.
CMS fleet management platform online monitoring
Mobile DVR work with professional fleet managment platform CMSV6, support PC Client software, Webpage client, mobile Android and IOS APP. It is very convenient to manage fleets, remote view live video and track position of all vehicles. Center people also can call driver and communicate with drivers by PTT speaker.
Installation
Mobile DVR and cameras are suitable to install on all kinds of vehicles like bus, truck, car, taxi,ambulance, van, tanker, tow vehicles, trailer...
Product Detail
Technical Parameter: | ||
Item | Device Parameter | Performance |
System | Main Processor |
Hi320d v400 |
Operating System | Embedded Linux OS | |
Operating Language | Chinese/English/Russian | |
Operating Interface | GUI, Support mouse and remote control | |
Password Security | Two Layer password Admin/User | |
Audio & Video
| Video Standard | PAL/NTSC |
Video compression | H.264/H264+/H265/H265+ | |
Image resolution | 1080P/720P/960H/D1/CIF | |
Playback Quality | 1080P/720P/960H/D1/CIF | |
Compound mode | A variety of ways | |
Decoding ability | 4ch 1080P | |
Recording quality | Class 1-6 optional | |
Image display | Single/QUAD display optional | |
Firmware upgrading | Upgrading mode | Manual/Automatical/Remote/Emergency Recovery |
Upgrading method | USB disk/Wireless network/SD card | |
Function Extension | GPS/BD/GLONASS | Support detecting antenna Plug in/Unplug/Short circuit |
2G/3G/4G | Supports CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE | |
WIFI | 802.11b/g/n, 2.4GHz | |
Others | Power input | 8V~36V DC |
Power output | 5V 300mA | |
Power consumption | Standby 8.5mA Maximum consumption 18W @12V 1.5A @24V 0.75A | |
Working temperature | -20 --- 70℃ | |
Storage Size | 1080P 1G/h/channel 720P 0.5G/h/channel 960H 0.38G/h/channel | |
Dimension | 142*153*33mm | |
Certifications
Company Information
about us
Eastyle Electronics was built in 2008, which is a manufacturer of Vehicle electronics products with well-equipped testing facilities and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in all kinds of vehicles like bus, truck, car, taxi, trailer, tanker...etc.
Contact Us
Related Products
Product Category
Packaging & Shipping
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
