Dankai Factory Hot Selling PTFE FEP Heat Shrinkable Tube 25mm

Product Overview

Description

Dankai Factory Hot Selling PTFE  FEP Heat Shrinkable Tube 25mm



PTFE tube, F4 tube, teflon tube, teflon tube, teflon pipe, teflon hose, PTFE pipe,PTFE hose,F4 pipe,F4 hose.



Product Image:















Product Description:

Product Name	Dankai Factory Hot Selling PTFE  FEP Heat Shrinkabl Tube
Material	PTFE,Teflon, F4
Color	Common colors:white tube, translucent tube, black tube. Unusual colors: yellow tube, brown tube, green tube, blue tube, red tube.
Size	ID*OD: 2*4mm, 3*5mm, 4*6mm, 5*7mm, 6*8mm, 8*10mm, 8*12mm, 9*12mm, 10*12mm,12*14mm, 14 * 16mm ,16 * 18mm,18 * 20mm and so on. Inch: 1/8 inch (1.6*3.2mm), 1/4 (3.96*6.35mm) 3/8 (6.35*9.525mm),1/2 inch (9.5*12.7mm), 3/4 (15.88*19.05mm), 1inch (22.2*25.4mm).                           PTFE Tube Can be customized size: inside diameter from 0.5mm to 200mm, wall thickness from 0.12mm to 3mm.
Incombustible	Does not burn in the air, in accordance with strict in fire place
Non-toxic	Avirulent insipidity, with physiological inert, no harm to people and environment
Packing	100meter/roll packed in a carton or wooden case
MOQ	100meter
Delivery Time	5-15days
Sample Time	2-5days
Sample Fee	Free When Use Your Express Account
Payment	TT/LC/Paypal/Alibaba trade assurance



PTFE Tube Features:
.Highly temperature resistant,operating temperature: -200°C~260°C
.Highly flame retardant

.Resistant to corrosion, strong acid, strong base, chemical reagents, and oil etc

.Corrosion resistance: can withstand besides molten alkali metals, fluoride medium and higher than 300 ° all strong acid, strong oxidizer.
Easy to flanging process

.High transparency:among all plastics, the lowest refractive index makes it possible to see clearly the flow of medium in the pipe
.RoHS compliant .

.Flammability: VW-1

.Standard color: transparent or white

Category	Unit	Index
Apparent Density	g/cm 3	2.16~2.20
Tensile Strength	MPa	18
Elongation at Break	%	230
Ultimate elongation (min)	%	200
Residual lubricant content (max)	%	0.5
Electrolytic Strength	Kv/mm	10



PTFE Tube Usage:

Low drug resistance, the viscosity of liquid transfer joint coating protection not part with the machine
The protection of the low sensor
Low metal ball of tackiness
The protection of the low temperature of drug use
Low fiber sheath outer cladding





About US:

Shenzhen dankai technology co., LTD. Was founded in 1998,Is located in shenzhen,China.is now developed into a leading and professional manufactory of PTFE /FEP/PFA, tube ,rod ,film and so on.

With most advanced machine,production lines ,after-sales service team and the techlogy the productivity per year now is more than 1000 tons.  Shenzhen Dankai is making every effort to let more and more customers enjoy good quality PTFE prodcuts with the most competitive prices.

Our products are exported to Europe, America, Africa and more than a dozen countries and regions, by domestic and foreign customers recognition and praise.



Main products :

· polyperfluoroethylene propylene (FEP, F46) transparent tubes, heat shrinkable tubes, corrugated tubes, special-shaped tubes, plates and films;

· fusible polytetrafluoroethylene (PFA) transparent tubes, corrugated tubes, special-shaped tubes and PFA welding rods;

· PTFE (PTFE, F4) insulation sleeve, liner, rod, plate, gasket, washer, elastic belt, braided packing;

· polyvinylidene fluoride (PVDF, F26) tubes;

· at the same time, we can process and produce fluorine plastic products of various specifications according to customer requirements.
