Машины для проектирования штукатурки и раствора

Product Overview

Description

 Now we also have dielse models!

Contact me for more details.







                                                            JP70-P  electric plaster machine



1. JP70-P,JP70-S is multi-functional large output plastering machine introduced Italian technology. And the worm pump design is same as IMER Step 120 (Putzmeister 2L6).



2.  It's suitable for different characteristics dry ready-mixed mortar construction.





3. With variable speed regulation, can achieve different pressure, output and plastering speed.







4. Sets the pressure controlling protection mechanism, and meets the remote control working requirement.



5. It can plaster 1000-1500m2 per 8hours. Max height to 30m while Max distance to 50m.



Technical parameters of JP70 Mortar plastering machine



Model	—	JP70-P	JP70-S	JP70A-50
Supply power	—	400V 50Hz	400V 50Hz	400V 50Hz
Motor power	kw	4.5/5.5	4.5/5.5	4/5.1 KW
Compressor power	kw	0.9	—	0.9
Maximum grain size	mm	6	6	6
Output	l/min	70	70	50
Delivery pressure	bar	30	30	30
Horizontal delivery distance	m	60	60	40
Vertical delivery distance	m	30	30	20
Hopper volume	L	120	120	50
Net weight	kg	275	275	180
Dimension (L×W×H)	mm	2040×820×950	2040×820×950	1500*650*650





1. The motor and air compressor of  JP70-P are both made in German.





2. The whole appearance of JP70-P plastering machine is very sample for easier maintance.



3. JP70-P is always used for pumping and plastering  mortar, fireproofing, thermal insulation etc.
