Phosphor Blue Light LED Full Wavelength 440 470nm 1W 3030 Ice Blue LED
- Category: >>>
- Supplier: Shenzhen Huaqisheng Opto-Electronics Technology Co. Ltd.
Share on (62061108433):
Product Overview
Description
| Product Name | 1W 3030 Ice Blue LED | Product Model | HQS-3030LB |
| Power Dissipation | 1.05W | Light Color | Phosphor Ice Blue |
| Forward Voltage | 2.8-3.4V | Viewing Angle | 120° |
| Forward Current | 350mA | Operating Temperature | -40~+60 ℃ |
| Luminous Flux | 15-20LM | Storage Temperature | -40~+85 ℃ |
| Wavelength | 440nm 450nm 460nm 470nm | Soldering Temperature | 260℃ |
| 3030 SMD LED SERIES SPECIFICATION | ||||||
| Product Name | Light Color | CCT/Wavelength | Voltage | Current | Lumen | Remark |
| 3030 LED | Gold Yellow | 1800-2000K | 3/6/9V | 350/175/100mA | 120-150LM | CRI80,90 |
| 3030 LED | White | 3000-10000K | 3/6/9V | 350/175/100mA | 120-180LM | CRI80,90,96+ |
| 3030 UV LED | UV | 365-370nm | 3/6/9V | 350/175/100mA | / | Epileds Chip |
| 3030 UV LED | UV | 390-400nm | 3/6/9V | 350/175/100mA | / | Epileds Chip |
| 3030 BLUE LED | Blue | 440-470nm | 3/6/9V | 350/175/100mA | 12-20LM | Epileds Chip |
| 3030 Green LED | Green | 520-530nm | 3/6/9V | 350/175/100mA | 70-100LM | Epileds Chip |
| 3030 Amber LED | Yellow/Amber | 590-610nm | 2/4/6V | 350/175/100mA | 20-25LM | Epileds Chip |
| 3030 Red LED | Red | 620-630nm | 2/4/6V | 350/175/100mA | 30-35LM | Epileds Chip |
| 3030 Far Red | Far Red | 660-665nm | 2/4/6V | 350/175/100mA | 12-15LM | Epileds Chip |
| 3030 IR LED | IR | 730-750nm | 2/4/6V | 350/175/100mA | / | Epileds Chip |
| 3030 IR LED | IR | 850nm | 2/4/6V | 350/175/100mA | / | Epileds Chip |
| 3030 PC Blue | Phosphor Blue | 450-470nm | 3/6/9V | 350/175/100mA | 15-30LM | Customized WD, WP |
| 3030 PC Green | Phosphor Green | 510-530nm | 3/6/9V | 350/175/100mA | 140-200LM | Customized WD, WP |
| 3030 PC Color | Phosphor Amber/Red | 600-630nm | 3/6/9V | 350/175/100mA | 50-60LM | Customized WD, WP |
