Rotary cermet trimming potentiometer WI20 10k ohm

Range of nominal resistance

100Ω~1MΩ

Resistance tolerance

±20%

Resistance Tape

B

Insulation resistance

1100Ω at DC500V

Withstand voltage

500V (DC or AC peak value)

Total rotational angle

300°±10°

Rated power

1W ( 220V max)

Max operating voltage

 20V

Slider noise

447m

Rotaional Torque

0.3~5 mN.m

Shaft stop strength

15mN.m

Push-pull strength

10Nmax

Rotational Life

10000 round
