CBB98/99 high voltage energy discharge defibrillation capacitor Replace AEROVOX

Product Overview

Description

CBB98/99  high voltage energy discharge capacitor Replace aerovox QL232EW196V23A



Application:

Product are suitable for external defibrillator/ AED.



Characteristics:

1.selects high temperature and high quality polypropylene film as the medium

2.use the advanced coating process

3.two different configuration:

1)CBB98 uses dry structure, plastic case

2)CBB99 uses oil-filled, Aluminum case

4.Max working voltage :6000VDC

5.Max energy storage:more than 500J

6. small size, long life



Technical Specification:

Project	CBB99	CBB98
Configuration	Aluminum Case,Oil Filed	Plastic Case,Dry
Operating Temperature	-20℃~55℃	-20℃~55℃
Capacitance Tolerance	±5%	±5%
Shock Testing	IEC 68-2-27	IEC 68-2-27
Peak Operating Voltage	1.067Un	1.067Un
Operating Atmospheric Pressure	375 to 760 mmHg	appx,4500m
Test Voltage	T-T:1.1Un60s T-C:2.17Un10s	T-T:1.1Un60s
Pulse life Rating	1.0E+4Pulses@25℃	1.0E+4Pulses@25℃
Max Dissipation Factor	1.5%@100Hz25℃	1.5%@100Hz25℃



Specification of Main Products:

Rated Capacitance (uF)	Rated Voltage (Vdc)	Joules (J)
32	5300	449
400	1500	450
185	2350	511
195	2300	516
185	2300	489
195	2300	516





The Above Form Shows Only Part of the Specifications and Can Design on the Basis of Custom Requirement.
