High Speed Stand up Pouch Zipper Plastic bag Three Side Sealing Bag Making Machines Video Technical Support
- Category: >>>
- Supplier: Ruian Ruipai Machinery Co. Ltd.
Share on (62070086643):
Product Overview
Description
Product Description
Model | RP-T500 |
Material | BOPP.COPP.PET.PVC, and nylon laminate film, aluminum foil laminate film, etc |
Final bag making type | Three sealing bag, stand bag, zipper bag |
Max. making speed | 30-150pcs/min |
Max. feeding speed | ≤35m/min(decided by material) |
Max. bag making length | 30-500mm×N(N≦6). |
Max. bag making width | 60-500mm |
Max. raw material unwinding diameter | Ф600×1250 |
Total power | 32kw |
Main power | 3.7kw |
Machine outside dimension | 11505×2300×1865mm |
gas resource | 0.6mPa(6kg/cm2 ) |
Weight | 5500kgs |
Equipped with | ||||||||
Parts | Items | Model | Quantity | Brand | ||||
Traction parts | Traction motor | Servo motor 1.5kw | 3pcs | Panasonic | ||||
Pneumatic parts | China | |||||||
Convey parts | reducer | 1:17 | 1set | Taiwan | ||||
Inverter | 3.7KW | 1set | Delta | |||||
Unwinding parts | Inverter | 0.75KW | 1set | Delta | ||||
Control parts | PLC | 1pc | Panasonic | |||||
LCD | 10inch | 1set | AOC | |||||
Solid relay | 24pcs | China | ||||||
Magnetic brake | 3sets | China | ||||||
EPC | Double photocell tracking | 1set | China | |||||
Photocell | SB-511 | 5pcs | Taiwan | |||||
Ultrasonic | 1pcs | China | ||||||
Related Products
After Sales Service
2. Engeneers available to service machinery overseas.
3. Training the operation and maintenance of the machines.
4. Online service all 24/7.
