Automatic lengthways plywood veneer slicer machine/wood veneer slicer machine

Product Overview

Description

Automatic lengthways plywood veneer slicer machine





The range of application:



Veneer slicer is designed to cut the sliced veneers out of high-valued wood with good grain and colour for surface coating.The veneers can be widely used in such fields as door making, Upholstery, panel furniture, surface of plywood and surface of MDF/partical board etc.



Main technical parameters:



Model	DB35T	DB25TT	DB25T	DB25V	DB20V
Max.working width	350mm	250mm	250mm	250mm	200mm
Max.working thickness	350mm	250mm	250mm	250mm	200mm
Infeeding speed	60m/min	50-80m/min	58m/min	58m/min	58m/min
Total power	33.75kw	25kw	24.25kw	24.25kw	17.25kw
Dimensions	3400x1630x2000mm	3400x1630x2000mm	3360x1630x2000mm	3360x1630x2000mm	2730x1240x1800mm
Weight	15000kg	8800kg	8500kg	8700kg	6500kg



 Key parts



1. All electrical components are from brand names at home and abroad,ensuring reliable performance



2. Slicing knife imported from Japan,enjoying long life span and guaranteeing veneer quality.



3. Operation system and control panel are made in Taiwan,featuring easy operation.



4. Infeeding belt is imported from Italy



Machine body:



1. Main parts of the frame are made of cast iron and experience heat treatment,avoid deforming and minimize shocks.

2. The chromed column and its aluminum-copper allooyed socket keeps wearing proof

3. The well-guideway ensures little friction,extending the life span of infeeding belts.



Performances:



1.Veneer output varies with cutting width and length. Generally speaking,the output can be 300-500 square meter hour

2.The table can be raised by power or hand wheel

3.A counter for veneers output is equipped

4.Automatic infeeding system with speed adjustable

5.For some soft wood,sliced veneers can be as thick as 10mm

6.Veneer thickness error can be+-0.1mm





About Us:



SHANDONG BAISHENGYUAN GROUP CO.,LTD

1. Leading manufacturer of woodworking machinery in China, found in 1956. specialize in this field for more than 60 years.

2. Almost 30 year export experience, exported dozens of countries in Asia, Europe, Africa and America. All products are quite popular among clients.

3.Specializing in plywood production line and finger joint board production line. We have our own designers to meet any of your requirement.

4. Having own after –sale maintenance center, our engineer can go to overseas for installation and commissioning.
