Luggage Scanning x ray machine for Ministry of Defense and Police

Tunnel size

1010mm*1005mm (W*H)

Conveyor speed

0.20m/s, Bi-direction scan

Conveyor height

300mm

Maximum load

200kgs(evenly distributed)

Wire resolution

40AWG(dia 0.0787mm wire)

Spatial resolution

Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire

Penetration(steel)

36mm guarantee, 38mm typical

Penetration resolution

32AWG(0.202mm)

Display

17 inch color LCD monitor,high resolution: 1280*1024

X Ray generator anode voltage

160Kv

Cooling cycle

Oil Cooling /100%

Beam direction

Downward

Image process

Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage

Material classification

Organic; orange;Inorganic:blue;Mixed and light metal:green

Section and magnification

Any area selection,1 -64 times magnification, support continuous amplification

Image pull back

Can pull back 50 images

Storage capacity

Can store at least 100000 pcs image

X ray leakage

<1μSv /h(at a distance of 5cm From external housing),meet all international and domestic health and safety standards

Film safety

guarantee ASA/ISO1600 Film

Software system

F1,F2,F3 programmable key,high density alarm,TIP;date/time display,

baggage Count, User management, System work timing, Radiation timing,

self-inspection while power on, save and search image, automatically

maintenance and diagnosis system, image recognition training.

Optional function

Video surveillance system, LED prompt screen, voltage

stabilizer, UPS back up

Physical size

3595.5*1685*1795mm (L*W*H)

Weight

980kgs

Operation temperature/Humidity

-10℃~+45℃; 5%~95%(non-condensing)

Storage Temperature/Humidity

-20℃~+60℃   5%~95% (non-condensing)

Operation power

220VAC (+/-10%) 50/60Hz

Power consumption

1KVA

Noise

Less than 55db
