70W 915nm Fiber Coupled Diode Laser Module 105um
Key features:Fiber: 105um/0.22NA/1m/Bare
Detachable fiber,Aiming Beam, PD, Thermistor functions optional
Quality Guarantee: Factory burn-in tested for 48hours and one year warranty for workmanship and materials after receipt of items.

Application:
Fiber Laser Pumping
Medical Application
Material Processing
Specification
Item No.: FC915DL70 Item Name: 70W 915nm Fiber Coupled Diode Laser
Parameter
Typical Value
Optical
Center Wavelength λ
915nm
Wavelength Tolerance
±10nm
Output Power
70W
Spectral Width FWHM
4nm
Slope Efficiency
5W/A
Fiber
Fiber Bend Radius
>40mm
Fiber Core/Cladding/Buffer Diameter
105um/125um/250um
Fiber Numerical Aperture
0.22NA
Fiber Length
1m
Fiber Connector
Bare
Electrical
Operating Current Iop
12A
Threshold Current Ith
0.6A
Operating Voltage Vop
13V
Power Conversion Efficiency
45%
Thermal
Operating Temperature
15~55℃
Storage Temperature
-30~70℃
Wavelength Temperature Coefficient
0.3nm/℃
