ZHUODI pressing machines hydraulic calibrator machine calibration system equipment

Product Overview

Description

Technique Table
Item no	Zhuodi pressing machinery	MOQ	One set	safe exporting package 3280x1700 new quartz stone pressing machine
Production Capacity	600m²/8 hours	Specification	6850×4000×3200mm
Brand Name	Zhuodi	Packing	Nude packing
Weight	112.2kw	Port of loading	Foshan
Power	380~415v	Guarantee	One year(for non-human factor malfunction)



PRESSING SYSTEM for 5th Generation Press Machine



Name	5th Generation Press Machine
Item Code	ZYJ1700
Motor	8*10kw
Power	4kw
Air Consumption	260L
Working Size	3250*1700mm
Weight	38Ton
Dimension	6950*3300*3000mm



PRESSING SYSTEM for Airbag Press Machine



Name	Airbag Press Machine
Item Code	ZQNYJ1650
Motor	10*12KW
Power	5.5kw
Air Consumption	260L
Working Size	3250*1650mm
Weight	56Ton
Dimension	6950*3300*300mm



CALIBRATING & POLISHING SYSTEM



Name	Oscillating Calibrating Machine
Item Code		ZYD800	ZYD1650
Grinding Segents		4-10	6-12
Work Width		600-800mm	600-1660mm
Work Thickness		10-40mm	10-40mm
Conveying Speed		1-3m/.min	0.8-1.5m/.min
Conveyor Motor Power		1.5-3kw	2.2-5.5kw
Swing Motor Power		2*4kw	2*4kw
The Grinding Head Motor Power		22kw	22kw
Water Consumption		210L/min	320L/min











1. Can you provide me with the product parameters

one polishing line two press lines semi-Auto distribution.

full production line dimension:117800*76840*14300mm(L*W*H)

Final slab dimension:760*2440mm;800*3100mm

thickness:10-30mm

daily capacity:360 slabs/day(20 hours)

annually capacity:260.000sqm/year



3. What is the size of the whole factory



one polish line can support 2 press lines

whole line dimension:136250*98280*10500mm(L*W*H)

Final slab dimension:1600*3200mm

thickness:10-40mm

daily capacity:480 slab/day(20hours)

annual capacity:720.000sqm/year

4. Do you have a perfect after-sales service system

with professional R&D team,providing pre-sales services,and timely solution.

12 year in engineered quarts stone production experiences,we can provide full training and technical support for our customers.we will

grow with our customers and develop new products with our customers.

with zhuodi machinery ,it's possible to produce any design of quartz.we also can customize and design the machine according to the actual demand,

ensure the easy operation during the production with the low cost,high production and high quality.
