L Long Running 192V Multi Application Factory Directly Hot Sale UPS 10KVA/8kw Single Phase Uninterruptible Power Supply

L Long Running 192V Multi Application Factory Directly Hot Sale UPS 10KVA/8kw Single Phase Uninterruptible Power Supply

Category: Uninterruptible Power Supplies (UPS) >>>
Supplier: Zhengxin,(Shenzhen),Technology,Co.,Ltd

Price:$288.00 - $328.00

Price in USD:Details

Quantity:

Product Overview

Description

High frequency 10KVA/8KW online ups for Instrumentation

China factory supply best quality online pure sine wave 10kva online ups prices

China

Product Introduction

Special Design to cater for Server Room and Precision Devices High Reliability by using the DSP Digital Controller

Product Features

Maintenance Bypass Switch to enable Zero on UPS Live Placement

Double Conversion UPS with 0.8 Power Factor with Up to 90% Efficiency

Multiple Communication Port from RS232 to Smart Slot or SNMP and SMS Monitoritng System

Complete Battery Management automatically adjust the Battery Termination Voltage to extend the battery lifespan

Optional Self-Maintenance Module can work while the machine still running

Technical Parameters

Single Phase Ups

Online Ups 10KVA/ 8KW
Load power factor is 0.8, adaptive for the develplent trend fo electrical Equipment and the load capacity is more strong Active input power factor correction (PFC), input power factor is over 0.98 Wide input voltage and frequency range, adaptive for extreme adverse grid environment of remote areas It can be connected with generators Zero transfer time effective ensures the safety and reliability of load operation
Specification		Single Phase In & Out
Rated output capacity		10KVA/8KW
Rated	Rated voltage	220VAC
AC input	Input voltage range	120-275VAC±5
	Input frequency range	(45-55)±0.5Hz
	bypass voltage	80VACx(1±5%)-285VACx(1±5%)
Battery Input	battery group voltage	192V 7Ah*16
	battery method	Outside
	Battery capacity & quantity	12V 7ah X16 PCS (optinal 20piece)
	backup time(half/full)	half load≥10 minutes,full load≥5minutes(standard)
	maximum input current when power on	<150% of rated current
	battery charging time	5hours can charge to 90%(standard) depend on the capacity of external battery group(long-running)
AC output	Output voltage	220VAC±1%(invert output)
	Output frequency	50±5Hz(when AC input is normal) 50Hz±1% (when ac inout is abnormal )
	wave form	sine wave THD<3%( linear load) sine waveTHD<8%(Nonlinear load)
	output power factor	0.8
	Overload Protection	105-125% ,Transfer to Bypass after 1 Min
	Output current peak coefficient	3:01:00
	Transfer time between AC and Battery	0ms
Communication and monitoring functions		RS232(can transfer to 485,Dry node,Smart slot(can expand to SNMP,SMS and other monitoring methods)
Tower	N.W(KG)	19.24
	G.W(KG)	22
	Unit Size(W X H X D)mm	502240455
	Carton Size(W X H X D)mm	595395590
Business Terms
Production ability		200 Piece/Pieces per Day
Delivery time	Sample delivery time	2 days
Delivery time	Order delivery time	18-21 days
Delivery port		SHENZHEN
Application area		Widely used in financial, telcom, govenment, traffic, manufacture, education etc.
Certification		ISO9001, ISO14001, CE, ROHS
