free flow drag conveyor chain
The Chain Conveyor, also called plate chain conveyor, is a mechanical system that operates in a seal pipe. Its feature is the stable property and saving the energy consumption in conveying system. It can contiguously convey bulky material, such as powder, fine particle and small lump and so on. It can convey in the level, the incline and the vertical. It widely applies in the chemical industry, the chemical fiber, the agricultural chemicals, ore, the food industry, the building materials, ect..
Product Description
Main structure of chains conveyer
1.Active part (handpiece)
1) motor reducer 2)drive sprocket 3)box 4)bearing 5)seal
2.Middle nodule
The middle pipe (including frange)
3.drive part
1)chains 2)discs 3)wall-cleaning device
4.The turning part
1)steering gear: the steering body, steering wheel, bearing block 2)The big bend(turn the elbow)
5.Inlet and outlet
(depend on certain requirement)
6.The passive part
1)the driven sprocket 2)passive box 3) Tensioner 4)bearing 5)seal
Technical parameter
Model |
conveying capacity (m³/h) |
Sprocket speed (r/m) |
Chains line speed (m/s) |
Power of motor (kw) |
GL80 | 4 | 20 | 0.29 | 4 |
GL100 | 8 | 18 | 0.31 | 5.5 |
GL150 | 16 | 15 | 0.31 | 7.5 |
GL200 | 28 | 12 | 0.3 | 11 |
GL250 | 48 | 10 | 0.3 | 15 |
GL300 | 60 | 8 | 0.28 | 18.5 |
GL400 | 80 | 8 | 0.28 | 22 |
Technology advantage
1. Scientific Design--In chain conveyor design, we have anti-off chain device and chain-broken protection device, matching color disc, the chain reverse recognition; add emergency outlet to ensure resume production rapidly.
2. Perfect Service--Have rich experience on manufacturing and installing. There are enough spare parts.
3. Rich Experience--Boyang chain conveyors have rich experience based on being use in most industries and treat widest range materials. Max Capacity is 300m³/h.Vertical conveying length up to 40 m,and horizontal conveying length up to 60 m.
4. Powerful Strength--Boyang Machinery Company is strong in technology and established research base with universities. It has two research centers. It is high-new-tech enterprise with more than 30 engineers and technicians.
5. Advanced Technology--Advanced control system,with online status detection system,could timely alarm interlock in the case of abnormal running to avoid equipment accidents.
6. Excellent Performance--The sofe disc could bear high temperature up to 250℃.The system could working at 500℃.
types of chain
1.Ring chains conveyor
| 1.Compact structure: change transport direction of the three-dimensional. 2.Fully enclosed transport, no dust spills, clean and environment friendly. 3.Lowest energy consumption, maximum lower operation cost during material conveying. 4.Maximnm conveying: 60m horizontal and 40m vertical,Maximnm capacity:300 m³/h 5.No dead area 6.No metal friction and lowest noise 7.Low maintenance costs 8.Long service life 9.Explosion and pressure shock resistant design 10.Can start with load. 11.Minimal ensure material integrity. |
2.Plate chain conveyor
| 1.Simple structure, Horizontal curves 2.The overall structure of the chains 3.Stable drive. 4.High strength and wear-resistance 5.Rolling friction ,reduce friction coefficient 6.Convenient dismounting |
3. Steel wire rope conveyer
| 1.Compact structure, Can be universal turning 2.No dead area 3.discharge at multiple points; no special airlocks 4.adjustable plate spacing 5.Suitable for small capacity material conveying 6.Cheaper than the plate chains, chains 7.Low maintenance cost |
