BIOBASE China Spectrophotometer LCD Screen Calibration Automatically UV/VIS Spectrophotometer Price
- Category: >>>
- Supplier: Biobase Biotech (Jinan) Co. Ltd.
Share on (62076816733):
Product Overview
Description
Product introduction
BK-UV1000/BK-V1000/BK-UV1200/BK-V1200 UV/VIS SPECTROPHOTOMETER
Features:
●Imported & Environmental Deuteriumlamp, preventing from Ozone inhalation
●High-class grating with wholly hermetic light path design, ensures the super low stray light
●Real-time monitoring the lifetime of Deuterium lamp and Tungsten lamp
●Socket-TypeDeuterium lamp and Tungsten lamp
●Wavelengthcalibration, wavelength setting, change light source and dark current calibration automatically
●Si02 coating opticalmirror, reduce theinfluence from outside
●Agriculture, Geology, Metallurgy and Environment etc. fields
Basic Fuctions:
1. Photometry
Test Abs., Transmittance by fixed wavelength
2. Quantitative
a. C Mode: EstablishC=K*A curve, test sample concentration
b. F Mode: EstablishA=K1*C+K0, test sample concentration
c. Display and save curve, test data (V-1200).
Photometry Mode Con. Test C=K*A+B
●Imported & Environmental Deuteriumlamp, preventing from Ozone inhalation
●High-class grating with wholly hermetic light path design, ensures the super low stray light
●Real-time monitoring the lifetime of Deuterium lamp and Tungsten lamp
●Socket-TypeDeuterium lamp and Tungsten lamp
●Wavelengthcalibration, wavelength setting, change light source and dark current calibration automatically
●Si02 coating opticalmirror, reduce theinfluence from outside
●Agriculture, Geology, Metallurgy and Environment etc. fields
Basic Fuctions:
1. Photometry
Test Abs., Transmittance by fixed wavelength
2. Quantitative
a. C Mode: EstablishC=K*A curve, test sample concentration
b. F Mode: EstablishA=K1*C+K0, test sample concentration
c. Display and save curve, test data (V-1200).
Photometry Mode Con. Test C=K*A+B
Technical
Model | BK-UV1000 | BK-V1000 | BK-UV1200 | BK-V1200 | |||||||||
Optical System | Single Beam, Grating1200 lines/mm | ||||||||||||
Wavelength Range | 200-1020nm | 325-1000nm | 200-1020nm | 320-1020nm | |||||||||
Spectral Bandwidth | 4nm | ||||||||||||
Wavelength Accuracy | ±1.8nm | ±1.5nm | |||||||||||
Wavelength Repeatability | ≤0.5nm | ||||||||||||
Photometric Accuracy | ± 0.002A (0-0.5Abs), ± 0.004A (0.5-1.0Abs), ± 0.5% T (0-100% T) | ||||||||||||
Photometric Repeatability | 0.001Abs (0-0.5Abs), 0.002Abs (0.5-1.0Abs),≤0.2% T (0-100% T) | ||||||||||||
Stray Light | ≤0.1 % T @ 360nm; 220nm | ≤0.2% T @ 360nm | |||||||||||
Stability | ± 0.001A / h @ 500nm | ||||||||||||
Noise | ± 0.001A | ||||||||||||
Display | LCD | ||||||||||||
Photometric Mode | T, A, C, E | ||||||||||||
Photometric Range | 0-200%T,-0.301-3.0A | ||||||||||||
Detector | Silicon Photodiode | ||||||||||||
Light Source | Deuterium Lamp, Tungsten Lamp | ||||||||||||
Input | Membrane Keypad | ||||||||||||
Output | Parallel Print,USB1.0 | ||||||||||||
Optional Accessories | Solid Sample Holder, Micro Cell Holder,10-100mm Cell Holder,PC software | ||||||||||||
Packing Size(W*D*H)(mm) | 560*430*320 | 560*430*320 | 560*430*320 | 560*430*320 | |||||||||
Gross Weight(kg) | 12 | 11.5 | 12 | 11.5 | |||||||||
Company information
Founded in 1999, having over 2000 employees (till February, 2020), BIOBASE Group is a new high-tech enterprise focusing on development, production and management of scientific equipment, In Vitro Diagnosis (IVD) instrument and reagent.
BIOBASE Group is specialized in products of 8 areas including medical diagnosis, biosafety protection, disinfection and sterilization, water purification system, infant care products, cold chain products, software products, clean room project.
