DN25 GRIP-Z STRAU METAL GRIPL NBR Stainless Steel Pipe Coupling for demanding applications
The GRIP-GZ coupling is designed to replace the need for flanging, welding, pipe grooving and pipe threading by providing a quick and easy solution to joining plain-end pipe.
The GRIP-GZ has two anchor rings which are placed adjacent to, but separate from, the sealing mechanism.
Suitable for pipes O.D φ30-φ168.3mm
Grip-GZ can come with AISI301 steel strip insert to reinforce sealing effect as well as prolong sealing sleeve's life.
Grip-GZ is a standard axial rstrain coupling with reinforced internal sructure so that can bear higher pressure.
We can customize for special requests.
Pipe outside diameter
Clamping range
Working pressure
Product O.D.
Width
Distance between sealing slips
Setting gap between pipe ends
Torque rate
Bolt
O.D.
Min-Max
Ship Industrial
Φ D
B
C
without strip insert
with strip insert (Max)
(mm)
(In.)
(mm)
(bar)
(bar)
(mm)
(mm)
(mm)
(mm)
(mm)
(Nm)
M
30
1.181
29-31
32
64
47.5
61
17
3~5
10
20
M8×2
33.7
1.327
32-35
32
64
51.5
61
17
3~5
10
20
38
1.496
37-39
32
64
58.5
61
17
3~5
10
20
M8×2
42.4
1.669
41-43
32
64
62.8
61
17
3~5
10
20
44.5
1.752
44-45
32
64
64.9
61
17
3~5
10
20
48.3
1.902
47-49
32
64
68.7
61
17
3~5
10
20
54
2.126
53-55
30
64
74.5
76
33
5~10
15
20
M8×2
57
2.244
56-58
30
64
77.5
76
33
5~10
15
20
60.3
2.374
59-61
30
64
80.7
76
33
5~10
15
20
66.6
2.622
64-68
30
64
90.7
96
37
5~10
25
40
M10×2
70
2.756
68-71
25
64
94
96
37
5~10
25
40
73
2.874
72-74
25
64
97
96
37
5~10
25
40
76.1
2.996
75-77
25
64
100.2
96
37
5~10
25
40
79.5
3.130
78-81
25
64
103.6
96
37
5~10
25
40
84
3.307
83-85
25
64
108
96
37
5~10
25
40
88.9
3.500
88-90
25
64
113
96
37
5~10
25
40
100.6
3.961
99-102
22
60
125
96
37
5~10
25
40
101.6
4.000
100-103
22
60
125.7
96
37
5~10
25
40
104
4.094
103-105
22
60
128
96
37
5~10
25
40
108
4.252
106-109
22
60
132
96
37
5~10
25
40
114.3
4.500
113-116
22
50
138.4
96
37
5~10
25
40
127
5.000
126-128
22
50
153.5
111
54
5~10
35
60
M12×2
129
5.079
128-130
22
50
155.5
111
54
5~10
35
60
130.2
5.126
129-132
22
50
156.8
111
54
5~10
35
60
133
5.236
131-135
22
50
159.5
111
54
5~10
35
60
139.7
5.500
138-142
22
50
166.3
111
54
5~10
35
60
141.3
5.563
140-143
22
50
167.9
111
54
5~10
35
60
154
6.063
153-156
22
50
178.9
111
54
5~10
35
60
159
6.260
158-161
22
50
185.5
111
54
5~10
35
60
168.3
6.626
167-170
22
50
191.5
111
54
5~10
35
60
NOTES:
The above tables are guides to the most common sizes. Couplings to suit specific outside diameters not listed may be
manufactured to order. Please contact us for further details.
