High Grass Lawn Mower

Product Overview

Description



Lawn Mower Features and Functions:

1. Lawn machine, here refers to a kind of mechanical equipment and green environmental protection equipment for cutting pasture. It cuts weeds in pastures and gardens, airs them, and uses the recycled hay for livestock feed.
2. The lawn mower is mainly used in garden decoration pruning, grass greening and pruning, urban streets, green spots, pastoral pruning, especially grass and grassland in the park, other grassland such as football field, private villa garden, and farm and animal pasture. The finishing of vegetation and other aspects can also be used during the autumn harvest.
3. The lawn mower that is commonly used today is a gasoline lawn mower, also known as a lawn mower. It is widely used for lawn trimming and beautification of park grasslands, green belts, factory grasslands, golf courses, home gardens, grasslands, orchards.

4.Smooth and easy to maneuver with 200mm sealed ball-bearing wheels, uses high quality compounds to enhance durability and drive traction.

5.The folding handle features an improved locking and pivoting system for ease of transportation and increased durability and rigidity.

6.Engine: DCM 1P64;Max power: 4.5/5/6HP; Start way: Recoil; Drive type: Hand push; Idle speed: 2850rpm;Cutting width: 400mm (16inch);Cutting height: 25-75mm, 10 adjustment; Height Adjustment: 1 lever adjustment; Wheel Diameter Front :6inch.

In operation
1. If the machine vibrates abnormally during operation, the engine must be stopped immediately.
2. The machine must be operated with both hands, and one-handed work is prohibited.
3. Never move your hands or feet close to the rotating blade while the engine is running
4. The side of the engine muffler needs to face outward to avoid burns

Correct mowing method
1. Because the blade is left-turning, the efficient working direction is to cut the grass from left to right.
2. The most efficient mowing is to cut two-thirds of the blade diameter into weeds.

After operation
1. Wrap the blade after use to avoid accidentally hurting others or yourself.
2. If you do not need to clear the fuel tank for a few days to avoid fire due to oil leakage.
3. Make sure the blade is completely stopped before performing the cleaning and maintenance inspection.
4. Remove the Mars plug wires to avoid accidental fire.
5. Wait until the engine has cooled down before storing.
6. Store the machine in a cool, dry place and keep out of reach.
7. Lubricating oil is added to the gearbox every 25 hours or 3 days, and the inner and outer tubes are lubricated.
8. Clean the air filter and spark plug every 50 hours or 8 days.
9. Clean the silencer and drum every 100 hours or 15 days.
10. Apply butter to the blade when not in use for a long time to avoid rusting the blade.



Model	Product Name	Product Details	Packing Size(cm)	G.W(kg)	Loading Qty(pcs)
NEALM-01 (CE GS)	Lawn Mower	Engine:Zf1P56F; Max.Power: 3.0HP; Displacement:99 Cc; Rated Speed: 3000r/m * Cutting Width: 400mm Cutting Height:25-75mm, 3 Positions * Collection Bag: 45L Fabric; Deck Material: Plastic* Drive Type: Hand Push Wheels Diameter:6/6; Noise:96Db(A) Features:Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor *High-Quality,  Impact Resistant Plastic Housing *3-Level Cutting Height Adjustment 25 Up To 75 mm; *Hard-Wearing Textile Grass Collection Bin With Large Volume	76.5*45*40.5	20.3	195/390/468
NEALM-02 (CE GS)	Lawn Mower	Engine:Zf1P60F; Max.Power: 3.5HP; Displacement:118 Cc; Rated Speed: 3000r/m; Cutting Width: 400mm; Cutting Height:25-75mm,  5 Positions; Collection Bag: 45L Fabric; Deck Material: Plastic * Drive Type: Hand PushWheels Diameter:6/8 Noise:96Db(A) Features: *Ergonomically,  Fold-Away Guidance Bar; *1 Cylinder,  4-Stroke Motor *High-Quality,  Impact Resistant Plastic Housing *5-Level Cutting Height Adjustment 25 Up To 75 mm; *Hard-Wearing Textile Grass Collection Bin With Large Volume	76.5*50*42.5	26.8	165/345/414
NEALM-03 (CE GS)	Lawn Mower	Engine:Zf1P56F; Max.Power: 3.0HP; Displacement:99 Cc; Rated Speed: 3000r/m; Cutting Width: 400mm; Cutting Height:25-75mm,  5 Positions; Collection Bag: 45L Fabric * Deck Material: Plastic *Drive Type: Self Propelled; Wheels Diameter:6/8; Noise:96Db(A) Features: Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor*High-Quality,  Impact Resistant Plastic Housing *3-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Textile Grass Collection Bin With Large Volume	76.5*50*40.5	24.7	165/345/414
NEALM-04 (CE GS)	Lawn Mower	Engine:Zf1P56F; Max.Power: 3.0HP; Displacement:99 Cc; Rated Speed: 3000r/m; Cutting Width: 400mm; Cutting Height:25-75mm,  7 Positions; Collection Bag: 45L Fabric; Deck Material: Steel Drive Type: Hand Push; Wheels Diameter:6/6; Noise:96Db(A) Features: *Ergonomically,  Fold-Away Guidance Bar; *1 Cylinder,  4-Stroke Motor *Shapely,  Backed-Enable Sheet Steel Housing *7-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Textile Grass Collection Bin With Large Volume	67*49*39.5	23.4	200/410/480
NEALM-05 (CE GS)	Lawn Mower	Engine:Zf1P60F; Max.Power: 3.5HP; Displacement:118 Cc; Rated Speed: 3000r/m *Cutting Width: 400mm Cutting Height:25-75mm,  7 Positions *Collection Bag: 45L Fabric *Deck Material: Steel * Drive Type: Hand Push Wheels Diameter:6/8 Noise:96Db(A)Features:*Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor *Shapely,  Backed-Enable Sheet Steel Housing *7-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Textile Grass Collection Bin With Large Volume	67*49*42.5	30.6	175/410/480
NEALM-06 (CE GS)	Lawn Mower	Engine:Zf1P56F; Max.Power: 3.0HP; Displacement:99 Cc; Rated Speed: 3000r/m * Cutting Width: 400mm Cutting Height:25-75mm,  7 Positions; Collection Bag: 45L Fabric; Deck Material: Steel * Drive Type: Self Propelled Wheels Diameter:6/8 Noise:96Db(A) Features:Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor *Shapely,  Backed-Enable Sheet Steel Housing *7-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Textile Grass Collection Bin With Large Volume	67*53*39.5	24.4	175/365/438
NEALM-07 (CE GS)	Lawn Mower	Engine:Zf1P60F; Max.Power: 3.5HP; Displacement:118 Cc; Rated Speed: 3000r/m; Cutting Width: 400mm; Cutting Height:25-75mm,  7 Positions; Collection Bag: 45L Fabric; Deck Material: Steel; Drive Type: Self Propelled; Wheels Diameter:6/8; Noise:96Db(A) Features: Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor *Shapely,  Backed-Enable Sheet Steel Housing *7-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Textile Grass Collection Bin With Large Volume	67*52*42.5	30.6	175/365/436
NEALM-08 (CE GS)	Lawn Mower	Engine:Zf1P64Fa; Max.Power: 4.0HP; Displacement:135 Cc; Rated Speed: 3000r/m; Cutting Width: 460mm Cutting Height:25-75mm,  6 Positions Collection Bag: 50L Plastic;Deck Material: Steel * Drive Type: Hand Push Wheels Diameter:7"/9.5" Noise:96Db(A) Features: *Ergonomically,  Fold-Away Guidance Bar *1 Cylinder,  4-Stroke Motor *Shapely,  Backed-Enable Sheet Steel Housing *6-Level Cutting Height Adjustment 25 Up To 75 mm *Hard-Wearing Plastic Grass Collection Bin With Large Volume	77*55*49.5	34.5	120/252/315







If you are interested in our Lawn Mower, please don't hesitate to contact us.
