Powder Coat Paint Professional Manufacturer in China
What is Powder Coating?
Powder coating is a new type of 100% solid powder coating which does not contain solvents. With no solvent, no pollution, energy and resources saving, recycling, environmental protection, higher performance, low health risk to workforce, economical advantages etc. Most powder coating is used by electrostatic spraying on metal surface, and then cure in oven, eventually form a solid layer.
Applications of Product
♦Electrical Household Appliances ♦Aerospace Area
♦Automotive Electronics ♦Fitness Equipment
♦Track Traffic ♦Medical Devices
♦Petroleum Pipes, Valve ♦Tools & Hardware
♦LED Lights, Outdoor Lamps ♦Radiator & Heat Sink
♦Glass Decoration ♦External Facilities

• Epoxy powder coating is a series of epoxy based powder coating designed to give optimum mechanical properties and exceptional protective qualities on components and fabrications where long term exposure to ultra violet light or exterior weathering is not anticipated.
• This series are available in a wide range of colors with different gloss and texture. Epoxy powder coating is perfect for indoor use.
MAIN PROPERTIES:
• Excellent corrosion protection;
• Excellent chemical resistance;
• High mechanical performance ;
• Suitable for interior use.
POWDER CHARACTERISTIC
• Chemistry: Epoxy
• Particle size: Suitable for electrostatic spraying
• Specific gravity: 1.2-1.8g/cm3 up to colors
• Curing schedule(object temp.): 160℃-180℃/10-15minutes;200℃/5-10minutes;
• Storage: Dry ventilation conditions below 30℃
COATING PERFORMANCE
Type A - 200°C (work piece temperature), 15 minutes (flat or Matt)
Type B -180°C (work piece temperature), 15 minutes (highlight)
Type C -140°C (work piece temperature), 15 minutes (highlight)
Inspection Item | Test Standard or Method | Test Indicator | |||
Type A | Type B,C | ||||
Impact resistance | ISO6272 | GB/T1732-1993 | 40cm | 50cm | |
Cupping test | ISO1520 | GB/T9753-1988 | 5mm | 8mm | |
Adhesion(Planning grid method) | ISO2409 | GB/T9286-1998 | Grade 0 | ||
Crook | ISO1519 | GB/T6742-1986 | 3mm | 2mm | |
Pencil hardness | ASTMD3363 | GB/T6739-1996 | 1H-2H | ||
Salt test | ISO7253 | GB/T1771-1991 | > 500 hours | ||
Heat test | ISO6270 | GB/T1740-1979 | > 1000 hours | ||
Heat resistance | 100°C/24 hours (white) | Paul Light character (best) :
| |||
Remark | 1, The above test use cold-rolled steel(thichness:0.8mm) to remove rust,oil. Film thickness: 50-70um. 2, All the indicators of film features will be down lightly depending on reducing of luster. | ||||




Hebei HANNA Technology branch factory ,
HANNA POWDERS ,
is an innovation-driven premium powder coating producer, with a mission to lead with technology and a deep root in customer service, HANNA POWDERS provides full range of services in powder coating to our customers, from powder coating R&D and fabrication, coating application technical supports and services, to customized coating solutions consulting services.HANNA POWDERS is technology focused, and our technical team are the industry leaders of powder coating. They share years of working experience and technical background from international powder coating companies. Their unique insight into the powder coating industry ensures the technological advantage of HANNA POWDERS .
At the same time combined with our advanced powder coating equipment technology ,
Continuously improve and upgrade the production process ,
Has won the global customer consistent high praise
With its emphasis on quality, HANNA POWDERS is a member of Qualisino, and HANNAPOWDER’s products have passed Qualicoat I, II certifications.BONDING products are the special focus of HANNA POWDERS. From equipment configuration, formulation design to manufacturing control, HANNA POWDERS sets the highest industry standard to fulfill the various requirements of our customers.
HANNA POWDERS will provide satisfactory services and quality coatings to our customers from our state of the art production centre in Shijiazhuang, China.
Our International Sales Team

Hanna Powders Factory Show

“HANNA POWDERS: Your Partner Powder Coating”
