Features:
l With 3D Deinterlace Decoding technology, the image is smooth;
l Support 3D digital comb filter and MPEG digital image noise reduction with sharper images;
l Fully support PIP and POP function, intelligent viewing mode.
l 5ms fast response time, no trailing;
l With ultra-quiet thermostat- Cooling Fan to lengthen lifetime;
l Low comsuption, Energy- saving, working life over 60,000H;
l The metal glaze paint housing, no radiation, durable;



Screen Size | 32inch |
Aspect Ratio | 16:9 |
Visible Size | 702.9mm (H)*397.3mm (V) |
Panel | TFT LED |
Max Resolution | 1920*1080 |
Display Color | 16.7M |
Pixel Pitch | 0.36375(H)*0.36375(V) |
Brightness | 500cd/m2 |
Contrast | 3500:1 |
Viewing Angle | 178°(H)/178°(V) |
Response Time | 5ms |
Field Frequency | 50-75Hz |
Lamp Life | >50,000 H |
Composite Video Input | 2CH BNC Input (BNC*2), can connect record device |
D-sub PC/VGA Input | 1CH D-SUB VGA Input |
HDMI Input | 1CH HDMI2.0 Input |
Audio Input | 2CH Mini Stereo (d=3.5)input |
Color System | PAL/NTSC |
Compatible HD/SD and HDMI Input | 400i/P, 576i/P, 720P, 1080i/1080P |
3D Deinterlace Decoding | Support |
3D Comb filter | Support |
MPEG Noise Reduction | Support |
PIP, POP | Support |
Language Menu | Chinese /English |
Voltage | AC 100~240V,50/60Hz |
Watt | 90W |
Standby Watt | <1W |
Heat Dissipation System | Ultra-quiet thermostat -Cooling Fan |
Housing | Metal glaze paint |
Wall mount dimension | 100mm*100mm |
725.2mm*422.9mm*43.9mm | |
Weight | 13.76 (wall mounts not included) |
Installation | Cabinet/ Wall-Mounted |
Accessory | Wall-mount bracket, Power Supply, Remote Controller, Manual , Warranty Card, QC pass card |
1. One year warranty for panels. If the panel is defected during warranty, you can enjoy free repair or replacement;
2. We have mature and complete process on tender protection;
3. OEM/ODM service can be offered. Customers' own logo can be printed or showed on the products or packages;
4. 1~2% free spare parts can be provided if the qty over 30pcs;
5. We can offer engineers door-to-door service if needed. But the charge of flight ticket and accomodation shall be paid by the customers.


1. Q: Are you a factory or trading company?
A: We are manufacture since 2004.
2. Q: What is your tender protection process?
A: Our process is: 1. let us know your tender basic information; 2. Revise our model numbers to yours before offering quotation list to your customer, and keep us known this special model numbers; 3. This tender information and special model numbers will be shared during our salesmen and also will be registered in our inner CRM system. In future, whoever get the inquiries from other companies, they will pass the inquires to your pointed salesman; 4. We will not give quotation to other companies until getting your guidance.
3. Q: What panel brand you use for LCD video wall?
A: Currently, we mainly use original Samsung or LG panels. And we also use BOE or CHIMEI panels in few cheap models.
4. Q: What is the warranty?
A: The panel default warranty is one year. If you need 3 years warranty, the cost will add 15%~20%.
5. Q: What payment method you accept?
A: We accept TT or west union. And you can pay 30% deposit for production, and 70% balance before shipment.
6. Q: What's the delivery time?
A: It depends on the order qty. 3~4 days for sample order, 5~7 days if order qty is ≤50pcs, 7~10pcs if qty is ≤ 100pcs. And over ≥100pcs, the lead time needs to be negociated.
