chicken manure sheep dung fertilizer bio organic fertilizer stirring teeth granulation machine

Product Overview

Description

1:Description

This roller granulator machine can process many types fertilizer (organic fertilizer, inorganic fertilizer(NPK), biological fertilizer, magnetic fertilizer, etc.). Especially to make rare earth, potassium fertilizer, and ammonium bicarbonate series compound fertilizer

 2:Feature

1)     the granules ball rate more than 85-95%

2)     the granules size:3-10mm

3)     The fertilizer granules compressive strength:10-25N

4)     Raw material moisture:>10%

3.Advantage

no need to add much water,no need to dry final products.

easy operation and maintenance

any kind of raw material can be processed,as long as the moisture is lower than 10%.

Room temperature,it can not break the raw material Physical properties.

4:Acceptable raw material:
  1)animal manure            2)food waste      3)house refuse

4)chemical material(NPK)     5)phosphate    6)potassic

7)metal ore powder           8)other organic raw material

9) Mineral powder           10) Bentonite powder 11)feed material

12)Borax    13) Ammonium chloride

5: Parameter

Model	YH-15	HY-22	HY-30
Granules size( mm)	Φ3.2-Φ6	Φ3.5-Φ7	Φ4-Φ8
Power(kw)	15	18.5	22
Roller size(mm)	Φ151*230	Φ151*310	Φ186*300
capacity (t/h)	1-1.5	1.5-2	2-3



My idea for your reference:



It often used in NPK fertilizer making,but if the raw material is dry and you also want to control the budget,you can choose this granulator machine.(no need drying machine and cooling machine). Low investment and good effects.
