H.265 MINI 3G 4G Wireless Speed Dome PTZ Camera 1080P WIFI Camera 360 Rotat 2MP 5X 20X Optical Zoom 2 Way Audio P2P SIM card SD
- Category: >>>
- Supplier: Shenzhen Qianpei Technology Co. Ltd.
Share on (62085482696):
Product Overview
Description
Product Description
MINI Wireless WIFI/4G PTZ Camera 2MP 5X/20X ZOOM
Summary
Outdoor PTZ speed dome camera, IP66 waterproof, up to 350m viewing distance with 20X zoom lens. Horizontal rotation with 360 degree no limeted position, vertical rotation from 0 to 95 degrees. The camera has two auxiliary light sources: white light and infrared light.3 type led light work mode can be selected: night infrared light mode/night white light mode and night smart auxiliary light mode. Wireless connetion, saving the trouble of wiring. Camera can record video to TF card, no need NVR and hard disk. With 2-way audio.
Features:
1, Power off memory function
2, Continuous 360° horizontal and 95° vertical rotation.
3, Wi-Fi/802.11/b/g/n ,PC CMS to control multi-cameras
4, Support Hikvision,, Dahua, NVR. ONVIF platform access, support mainstream ONVIF NVR protocol access,
5, Motion detection, email alert, FTP upload
6, Support Video Mask and Special Area Dection
7, Built-in power surge/lightning protection
8, Support IE remote browse, password for remote management, streaming media forwarding phone HD monitor
9, Supports 360° automatic scan; Support cruise scan between 2 presets; Support preset point;
10, P2P, PNP: Plug&play, Support QR code scanning to view on Iphone and android Mobiles
11, Network outages automatically recovery function
12, H.264/H.265 video encoding, support dual-stream, AVI format; support stream 0.1M ~6Mpbs Adjustable;
13, 5X/20X optical zoom optional
14, Networking: 2G:GPRS/EDGE; 3G:WCDMA/TD-CDMA; 4G:FDD-LTE/TDD-LTE; Wi-Fi:802.11/b/g/n. Network mode selection:Auto mode/3G-4G mode/WiFi mode
15, Band information: WiFi AP: 802.11/b/g/n; TDD-LTE: Band 38/39/40/41; FDD-LTE: Band 1/3; WCDMA: B1/B8; TD-SCDMA: Band 34/39; GSM/GPRS/EDGE: 900/1800
Specifications
Camera Specification | ||
Products Model | WNDR-4407-105X | WNDR-4407-120X |
Sensor | 1/3" Progressive Scan CMOS (Hi3516E+Sony307) | |
Effective pixels | 1290*1080 | |
Lens | 5X ZOOM F=2.7mm-13.5mm | 20X Zoom F=4.7mm~94mm |
Zoom | 5X optical zoom | 20X optical zoom |
Coding chip | 1/3" Sony307 | |
Total pixels | 2.0Megapixels | |
Synchronous mode | Internal synchronization | |
Signal system | PAL/NTSC | |
Minimum illumination | Color: black and white 0.1Lux: 0.01Lux | |
Camera OSD display | English menu | |
Exposure mode | Automatic / manual | |
mirror function | Support (mirror horizontal + vertical mirror) | |
Digital noise reduction | 2D Digital noise reduction | |
Electronic shutter | 1/25s~1/10,000s | |
PTZ Specification | ||
Laser light | 4pcs infared + 4pcs white LEDS White leds 50m/infrared leds 100m night vision distance | 8pcs infared leds infared leds Effective IR distance up to 150m |
Horizontal rotary speed | 1°~60°/S; | |
vertical rotary speed | 1°~60°/S; | |
Rotation range | Horizontal: 0°~ 360° continuously; vertical: 0°~ 95° | |
Preset | 255 (include special preset command) | |
Scan mode | Preset/cruise/horizontal scanning | |
Idle action | Support guarding position and before control action | |
Video encode | H.264/H.265/M-JPEG 96k~6M BPS encoding, bit rate, frame rate adjustable, support three bit stream | |
Network protocol | TCP/IP,HTTP,HTTPS,NTP,ICMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,PPPoE,P2P,802.1X,SCTP,SIP | |
TF Card | Optional (with external TF card slot, support 64G MAX) | |
P2P phone view | Camhi APP for iOS, Android P2P mobile phone monitoring | |
Network interface | 1 * RJ45 10M/100M adaptive Ethernet port | |
Night vision image | Ordinary:Black&white night Color: Color night Intelligent:B&W, auto switch to color on motion detection | B&W Night vision |
guard position | Support | |
Audio function | 2-way audio, support voice intercom, audio compression: G.711 8K sampling, 1 input 1 ways of output | |
Power off memory | Support | |
Structure | 4 inch half metal structure | |
Humidity | ≤95% Non Condensing | |
Power | DC12V ≤3A(Waterproof power) | |
Consumption | < 25W | |
Lightning Protection | Transient voltage 3000V | |
Bracket | Standard wall mounting (Hoisting optional) | |
Weight | 1.8KG | |
Packing Size | 27*15*21cm | |
Waterproof | IP66 | |
Package Incllude:
- 1 x PTZ Camera
- 1 x Power supply
- 1 x Scren bag
- 1 x Manual
(Memory card optional)
