China manufacturer supply high speed centrifugal reflux pump for amine liquid regenerator

industrial high speed centrifugal pump for amine liquid regenerator

High-speed pump refers to the high speed pump, generally the pump speed is higher than 3600 r/min.
High-speed centrifugal pump has advantages of high single-stage lift, compact structure, convenient maintenance and high reliability, is widely used in petroleum refining, petrochemical industry, coal chemical industry, fine chemical, fertilizer, gas, chemical, desalination, smelting, clean energy, medicine and chemical industry, light industry, environmental protection, black, non-ferrous mineral, thermal power plant, alumina, phosphate, potash fertilizer, iron and steel, river dredging, etc.
The high speed pump is composed of motor, accelerator and pump body. Generally, horizontal structure is adopted when the motor power is large.
Features:
GSB-S series horizontal high speed centrifugal pump is mainly used for small flow-rate and high lift. It has two-stage and single suction pump head, can be operated in series or in parallel according to the requirement.
The speed accelerating box is a horizontal split structure with a first-stage speed increasing. One low-speed gear shaft drives two high-speed gear shafts at the same time to drive the impeller.. The dynamic balance accuracy grade of high-speed shaft reaches G1.0, and the gear manufacturing accuracy grade reaches GB/T 10095 level 4.The front and back radial bearings of the high-speed gear shaft adopt tilting pad axle sliding bearing. High precision parts make this series pump running smoothly with small vibration and low noise.
