Product Overview

Description

New Arrival High Power 4G/5G Wireless Router With IEEE802.11N/G/B/AC



YN-SR01 is a 5G industrial router, which makes the data interaction between machine equipment and the platform more efficient. The characteristics of 5G ultra-high speed, ultra-large link, ultra-low latency, and secure transmission.

Built-in Qualcomm 4-core series CPU, large flash memory, high-speed memory, strong data processing capabilities, support for dual-frequency concurrency, multiplying the number of computers, at the same time, it has a reliable all-round quantity and network security, and comprehensively helps solve the efficient operation of enterprises.





1. Adopting the world's leading Qualcomm 4-core ARM Cortex-A7 IPQ4018/28, CPU clocked at 600Mhz, and use Qualcomm X55 industrial-grade wireless communication module to ensure that the product can run stably for a long time in harsh environments.

2. Using metal shell, high protection level, static electricity 15000KV, surge 4KV, high temperature and wide voltage, can withstand extreme temperature, voltage instability, high electromagnetic radiation and harsh conditions to ensure continuous communication between remote equipment and monitoring center.

3. 5G industrial routers are fully compatible with the networks of all countries, including seven network standards including TD-LTE, FDD-LTE, TD-SCDMA, WCDMA, EVDO, CDMA1X, GPRS/EDGE, etc. Operators can be switched flexibly and freely according to operational needs, network selection is more convenient, and traffic tariffs are more economical.

4. 2.4GHz and 5.8GHz dual-band WiFi, users can choose to connect.

5. With 8 widened high-performance antennas, through scientific layout, in a limited space, the same frequency antennas can obtain greater isolation, effectively reduce the same frequency interference, and improve the data transmission and reception capabilities.

6. Large memory and large storage design to meet different needs;

7. 1 Gigabit WAN port, 4 Gigabit LAN ports, 1 CONSOLE port WAN port supports POE power supply (12-48V)

8. Support 11AC, wireless maximum can reach 1200M, meet various application scenarios,

9. Support 2.O/3.0USB interface, fast shared mobile storage network;

10.Hardware watchdog design, to achieve all-weather use without hindrance,

11.Support Open-Wrt system, convenient for customers to develop by themselve



Model	YN−SR01
CPU	ARM Cortex-A7 IPQ4018/28,CPU clocked at 600Mhz
OS	QSDK / OpenWRT
Wireless Rate	2.4G:2T2R:300Mbps;5.8G:2T2R:866Mbps
Protocol	IEEE802.11N/G/B/AC
Memory	DDR3:256MB, Max256MB
FLASH	32M,Max128MB
4G/5G	4G/5G design 3.0 USB line, support 4GMINI-PCIE, M.2 2G 3G 4G 5G module sharing
Interface	Support 1 10/100/1000M adaptive WAN, support auto flip (Auto MDI/MDIX) Support 4 10/100M/1000 adaptive LAN, support auto flip (Auto MDI/MDIX) Support 1 CONSOLE port, convenient for debugging; default not posted Support 1 2.0 USB interface Support 1 3.0USB interface
Protection	ESD Protection Grade: IEC61000−4−2 Surge Protection Grade: IEC61000−4−5
Power Supply	Inner 40W,WAN port Support POE/12−48V/2a−0.5A
Frequency	2.4G: support 802.11b/g/n     5G: 802.11a/n/ac
Power Consumption	The maximum full load is 20W, the normal operation is about 8W
RF	2.4G:23dBm.:sky85309  5.8G:23dBm.:sky85728
Working Temperature	−30~±75°C
Working Humidity	10% to 90%RH non-condensing
Storage Temperature	-40℃ to 100℃
Software Features	Support AP, router, relay, 4G function, etc. Support VPN security tunnel function, Support dynamic routing and static routing Convenient WEB configuration Wireless setting and encryption method Support telnet management, convenient and easy-to-use console shell interactive environment Support multiple dialing methods: automatic allocation, designated IP, designated local peer IP, ppoe Support local software upgrade; support configuration export and import, and web online update firmware program Support operating system Windows XP/7/8/9/10/Linux





5G industrial routers have been widely used in the M2M industry in the IoT industry chain, such as smart factories, smart medical, smart ports, and new media video transmission.
