CNC Boring Center Machine with Six Sides SHCNC 6FSB2500 with Workpiece length 200 2500mm and Workpiece width 50 1200mm
- Category: >>>
- Supplier: Yantai Shoot CNC Machine Co. Ltd
Share on (62095174179):
Product Overview
Description
Product Description
| CNC Boring Center Machine with Six Sides | |
| Model | SHCNC-6FSB2500 |
| Workpiece length | 200-2500mm |
| Workpiece width | 50-1200mm |
| Workpiece thickness | 10-60mm |
| Pressing Group speed | 80m/min |
| Y axis speed | 75m/min. |
| Z axis speed | 30m/min. |
| Cutter quantity | vertical 12pcs + horizontal 2 group 4pcs |
| Drill chuck size | 10mm |
| Overall size | 5020x2530x2080mm |
| Total power | 15.63kw |
| Work air pressure | 0.6Mpa |
| System | Delta |
| Rail and screw | Taiwan |
| Drill bag | Taiwan |
| Electrical | SIEMENS |
| Product Advantage | |
| No need to flip the board. The equipment has six working parts (upper, lower, left, right, front and back) in six directions, so it can complete six working procedures (drilling, grooving, milling) in one time and consistently. It can save the time and manpower of traditional turning plate to the greatest extent. It can not only improve the production efficiency, but also reduce the power consumption of workers in production. | |
| Intelligent sweep code The device has intelligent scanner recognition and import of artificial intelligence system. When workers produce, they only need to scan the two-dimensional codes on the board, and the equipment can intelligently identify which part of the order is, and intelligently adapt the required processing system files to automatically import into the system. It can minimize order confusion and unnecessary plate loss caused by importing mismatched processing system files. | |
| Dual Execution Mode The device has dual execution mode. It can either directly execute command work with traditional programming mode or read and process system files to execute command work. When using the software, it is suggested to use the mode of reading files, which can save programming time to the greatest extent and improve production efficiency to a greater extent. Combining with the use of the software, it can effectively reduce the dependence on the programming technology level of workers, and is more conducive to meeting the needs of human resources for recruiting and new employees to quickly and skillfully take up their posts. | |
| Larger processing area This equipment supports the largest plate size of 4000mm x 1250mm, whether it is a noble floor wardrobe door panel, or a luxurious atmosphere cabinet cabinet, (drilling, grooving, milling round) and other processing processes are more skilled. With a vast processing area, it can meet the design needs of customized furniture designers. | |
| More drill shafts This equipment is equipped with luxurious configuration of double drill bags and has more drill shafts. The top drill contains 11 drill shafts and the bottom drill contains 6 drill shafts. Among them, there are 8 drill shafts in four positions (front, back, left and right), and 25 drills can be assembled at the same time. Even in the face of processing with various aperture sizes, it can be easily completed at one time without changing the drill bit (drilling, grooving, milling circle). | |
| More stable accuracy The equipment is equipped with intelligent side-leaning with rollers, intelligent lifting positioning system, movable supporting platform, air-floated bead supporting platform, etc. Intelligent double gripper is used to make the plate hold more steadily, locate more accurately and drag more smoothly. The above luxury configurations only pursue more stable accuracy, higher accuracy of hole spacing, higher natural efficiency and more handy furniture installation. | |
| Hardware Configuration | |
| Guide | Taiwan Silver |
| Cylinder | AirTAC |
| Server | New generation |
| Integral Control Software | Independent research and development of software |
| Industrial control | New generation |
| Rack and pinion | Foster |
| Multiaxial High Speed Drilling Bucket | Taiwan Pu Deng |
| Low voltage electrical apparatus | Schneider |
| High speed bearing | Germany SKF |
| Flexible towline cable | Germany CC |
| High Definition Display | 17 inches |
| Photosensitive switch | OMRON |
| Large Torsion Reducer | Foster |
| Solenoid valve | AirTAC |
Packaging & Shipping
Packing: by Plywood Case or Plastic Film
Shipping: Qingdao Port
Deliver time: 30days after receive payment
Company Information
Yantai Shoot Import & Export Co.,Ltd
Yantai Shoot Woodworking Machine Co.,Ltd
wechat: 0086 13906451612
whatsapp: 0086 13906451612
viber: 0086 13906451612
website: www.shootmachine.com
Our Services
Sample Availability & Policy
We can supply a sample machine for you to test, but you need to pay all costs, including machine's cost, shipping cost and customs cost.
Guarantees/Warranties/Terms and Conditions
One year
Export/Import Processing Support
We supply high-quality machine products for our clients, we deliver machine on time according to the sales contract. If the clients have other requirements, please ask us to help you.
After Sales Service
After the clients order our machines, we supply free support for one year. If the clients have questions, we can reply in 24 hours.
Prototyping
We have the expertise for reverse engineering, rapid prototyping and tooling design etc..
We can transform your drawing into a sample in a few weeks. If you don't have a drawing, send us a sample. We can measure your sample accurately, convert the data into 3D models or 2D drawings. We will forward the drawings for your approval and prototype according to the drawings.
Machining
Our combined facilities enable us to machine products to your standards. We utilize CNC equipment to make complex and high tolerance products
Assembling
We do many types of assembling. This will allow you to purchase a finished product rather than just a component.
Quality Control
Our inspectors test the products we sell for durability, accuracy and performance. We sell only quality products that meet or exceed your standards.
Training
A.Customers can get free technical training in our factory or online. Mainly training are as follow:
1.Software operation
2.Machine operation and maintenance
3.Instruction of technical parameters, as well as their setting ranges
4.Solutions for common problems
B.Also we can dispatch our technician to customers' place if customer agrees to pay visa cost,air ticket, accommodation and USD150/day/person training fee .
FAQ
1. Where you ship?
We ship worldwide to all the major ports and then transport by train or truck to your warehouse or the trucking terminals in your area. For special orders, we ship by airfreight or by express mail service through FedEx, UPS, DHL, TNT etc.
2. What is the approximate shipping time?
Express mail service like UPS, FedEx takes less than a week. We work closely with the shipping companies for the shortest delivery time.
3. What is the payment method?
We prefer irrevocable letter of credit. Telegraphic transfer is also accepted.
4. How will we handle quality issues?
Should there be defects in materials and workmanship, we will refund you with replacements from next delivery. We are not responsible for consequential damages resulted from these defects.
5. How do you pack?
We pack in heavy duty corrugated cartons or wooden crates and then strapped to pallets or steel pallets. We fumigate the wooden packages and have them degased.
6. Do you do private labeling?
Yes. We may apply private labeling and bar coding to the products you order. We can imprint your product number, your logo onto the products and the packages.
