Product Overview
Description
M35(Cobalt 5%)，M42(Cobalt 8%)，HSSM2，HSS4241，HSS4341
*D / Diameter: 3-5,2mm
*L1 / Total length: 46-62mm
*L2 / Working length: 10-16mm
*L1 / Total length: 46-62mm
*L2 / Working length: 10-16mm
* Double-ended, right-hand cutting, type N, works standard
* High-performance high-speed steel
* 135° conical section
* Diametral tolerance h8
* Fully-ground
* Cross-ground finish to DIN 1412 C
* For drilling thin sheets for car bodies and metal fabrication, for rivet holes, screw holes etc., in steel, zinc, brass,
aluminium, copper sheet and plastic panels.
* In all rotary and percussion drilling machines
* In machines for mechanical processing
* High-performance high-speed steel
* 135° conical section
* Diametral tolerance h8
* Fully-ground
* Cross-ground finish to DIN 1412 C
* For drilling thin sheets for car bodies and metal fabrication, for rivet holes, screw holes etc., in steel, zinc, brass,
aluminium, copper sheet and plastic panels.
* In all rotary and percussion drilling machines
* In machines for mechanical processing
Product Name | HSS Drill Bits | ||||||
Material | M35(Cobalt 5%)，M42(Cobalt 8%)，HSSM2，HSS4241，HSS4341 | ||||||
Surface Finish | Black Oxide/Titanium/Bright/Black&Gold /Amber/ | ||||||
Point Angle | 118°/135° | ||||||
Process | Fully Ground， Milled， Rolled | ||||||
Standard | |||||||
Point Type | 118 Degree Regular Point (1-3mm)， 135 Degree Split Point(3-20mm)，Turbomax point，Chip Breaker Point，Pilot Point，Point For Weld Spot | ||||||
Shank Type | Straight Shank，Reduced Shank，1/2Reduced Shank，Tri-Flats Shank，DIN3126.C Hex Shank，DIN3126.E Hex Shank，Double R Hex Shank，Morse Taper Shank，Threaded Hex Shank | ||||||
Size | 1 - 20mm、1/16" - 1"，A - Z，1# - 90# | ||||||
Package | Skin Card，Sticker，Slide Card，Blister Card，Double Blister Card，Color Label Bag，PVC bag，Plastic box，Hang Bag，Poly Bag，Sandwich Packaging | ||||||
Delivery Time: | 3-30days according to your order quantity | ||||||
Application
HSS Grade | Stainless Steel | Iron | Aluminum | Carbon Steel | Tile | Plastic |
M42 | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | × | ⭐⭐⭐⭐⭐ |
M35 | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | × | ⭐⭐⭐⭐⭐ |
M2 | ⭐⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | × | ⭐⭐⭐⭐⭐ |
HSS 4341 | ⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐ | × | ⭐⭐⭐⭐ |
HSS 4241 | ⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐ | × | ⭐⭐⭐⭐ |
