Pre Needle loom/Needle Punching Machine
Functionality & application:
1.By means of the needle punching process, the fiber will be entangled to create the cohesive force that makes the fiber web to be bonded.
2. Applicable for making a variety of nonwovens: carpet, felt, interlining, geotextile, filtration media etc.
Features:
1. Individual feeding roller with guide rings
2. Automated and frequency conversion controlled
3. Input and output speed controlled respectively
4. Advanced combined structure enables the excellent stabilization
5. Computerized random distribution of needles
6. Separated lubrication system
7. Easy operation and convenient maintenance
Main technical data:
Needling frequency:
|
≤600 t/min
|
Working width:
|
2000mm~9000mm
|
Needle stroke:
|
60-90mm
|
Stroke type:
|
Up-stroke ; Down-stroke
|
Needle density:
|
2000~5000n/m
|
Selected component suppliers : Siemens ; Siemens Beide ; TWB; NSK; CHINT; etc.
|
