Mining Machine Gold Copper Ore Grinding Ball Mill For Sale

Mining Machine Gold Copper Ore Grinding Ball Mill For Sale Brief Introduction:
The copper ore grinding ball mill is a key equipment to grind the crushed materials, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics.

Mining Machine Gold Copper Ore Grinding Ball Mill For Sale Application:
Gold grinding ball mill is a kind of key equipment for milling the materials into powders after they are crushed. Gold copper ore ball mill is widely used for cement, the silicate product, new type building material, fire-proof material, chemical fertilizer, black and non-ferrous metal, glass, ceramics and soon, and can make the dry and wet milling on all kinds of ores and other grindability materials .

Detailed Images

Working Principle of Mining Machine Gold Copper Ore Grinding Ball Mill :

The grinding ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Mining Machine Gold Copper Ore Grinding Ball Mill For Sale Technical Parameter:

Model	Speed (r/min)	Max. weight of balls (t)	Input size (mm)	Output size (mm)	power (kw)	Capacity (t/h)	Weight(t)
Φ900×1800	37	1.8	≤15	0.075-0.89	15	0.5-2	3.4
Φ900×2100	37	2.3	≤15	0.075-0.4	18.5	0.4-2	3.9
Φ900×3000	35	3.85	≤25	0.075-0.4	30	1.1-2.5	7.78
Φ1200×2400	35	4.6	≤25	0.075-0.4	30	1.3-3.2	8.65
Φ1200×2800	35	5.4	≤25	0.075-0.4	37	1.5-3.7	10.02
Φ1200×4500	35	8.6	≤25	0.075-0.4	45	2.7-6.79	14
Φ1500×3000	29	9	≤25	0.047-0.4	75	3.3-8.2	14.12
Φ1500×3500	29	10.5	≤25	0.047-0.4	75	3.3-8.5	15.64
Φ1500×4500	29	13.5	≤25	0.047-0.4	90	4.5-12	20
Φ1500×5700	29	17	≤25	0.047-0.4	110	2.6-14	21.5
Φ1830×3000	24	13.5	≤25	0.047-0.4	135	4-15	28
Φ1830×3600	24	14	≤25	0.047-0.4	135	4-15	29
Φ1830×4500	24	20	≤25	0.047-0.4	155	4-19	32
Φ1830×7000	24	31.5	≤25	0.047-0.4	210	6-22	37.5
Φ2100×3000	22	18	≤25	0.047-0.4	210	6.4-28	40.79
Φ2100x3600	22	20	≤25	0.047-0.4	210	7-28	42
Φ2100×4000	22	21.5	≤25	0.047-0.4	210	7.6-28	43.45
Φ2200×3600	21.7	25	≤25	0.047-0.4	245	5.2-32	44
Φ2200×7000	21.7	46	≤25	0.047-0.4	380	15-38	63
Φ2400×3600	21	28	≤25	0.047-0.4	320	8-60	47
Φ2400×4500	21	35	≤25	0.047-0.4	380	8.5-60	70.5
Φ2700×3600	20.7	40	≤25	0.047-0.4	400	12-80	75.5
Φ2700×4500	20.7	48	≤25	0.047-0.4	450	12-90	102
Φ3200×4000	18	65	≤25	0.047-0.4	800	30-180	137
