XA6132 XA6140 knee type universal horizontal milling machine

XA6132 XA6140 knee type universal horizontal milling machine

Main Specification

XA6132 XA6140 knee type universal horizontal milling machine

Structure and performance characteristics:

The machine itself has sufficient rigidity, can carry heavy cutting work

The machine has enough power and a wide range of speed, can give full play to the effectiveness of the tool, and can use carbide cutting tools for high-speed cutting

Spindle speed impulse device, easy to speed.



MAIN TECHNICAL DATA

UNIT

XA6132/X62W

XA6140/X63W

Table size

mm

1320×320

1700×400

Table T-slot (slot number x width x pitch)

mm

3-18-70

3-18-90

Maximum table load

g

500

800

X direction (vertical) manual/auto

mm

700/680

900/880

Y to(slide seat horizontal) manual/auto

mm

255/240

315/300

Z direction (vertical)manual/auto

mm

320/300

380/360

Cutting feed speed

mm/min

X.Y:23.5-1180 Z:8-394

X.Y:23.5-1180 Z:8-394

Rapid moving speed

mm/min

X:2300 Y:2300 Z:770

X:2300 Y:2300 Z:770

Spindle speed range

rpm

30-1500

30-1500

Spindle speed step

( steps)

18

18

Swivel angle of table



+_45°

+_45°

Distance from spindle center to table

mm

30-350

30-410

Spindle power

kw

7.5

11

Dimensions

mm

2294×1770×1665

2560×2130×1800

Machine weight

kg

2650

3850



Details display

 XA6132 XA6140 knee type universal horizontal milling machine

XA6132 XA6140 knee type universal horizontal milling machine

This machine uses:

This series of universal lifting machine milling machine The product easy to operate, reliable performance, widely used in various types of mechanical processing sector, processing a variety of plane, grooves, gears and so on. Configuration universal milling head, round table, dividing the  first class milling machine accessories, can further expand the use of machine tools



Packaging & Shipping

XA6132 XA6140 knee type universal horizontal milling machineXA6132 XA6140 knee type universal horizontal milling machine

Packing Size

2294×1770×1665mm

Packing Weight1450kg
Packing mothedNude, or wooden case, or customer's request
20'GPAbout >4 sets
40'HQAbout >10 sets
MOQ1 set
Delivery time7-25days
