100% bayer tinted pc solid polycarbonate sheet for bus station sound barrier
- Category: >>>
- Supplier: Hangzhou Saining Polycarbonate Sheet Co. Ltd. [Zhejiang China]Hangzhou
Share on (62104750211):
Product Overview
Description
Product description
| Polycarbonate solid sheet Product Standard & Technical Parameters | ||||||
| Thickness(mm) | Weight(kg/m2) | Mini-bending radius(mm) | Width(m) | Length(m) | Colour | |
| 1.1 | 1.32 | 234 | 1.22-2.1 | no limited,It can be rolled like 30 meter | Clear, Green, Blue ,Brown ,Opal ,Red ,Yellow. | |
| 2 | 2.4 | 360 | 1.22-2.1 | |||
| 3 | 3.6 | 540 | 1.22-2.1 | |||
| 4 | 4.8 | 720 | 1.22-2.1 | |||
| 5 | 6 | 900 | 1.22-2.1 | ≤5.8m for 20ft, ≤11.8m for 40ft | ||
| 6 | 7.2 | 1080 | 1.22-2.1 | |||
| 8 | 9.6 | 1440 | 1.22-2.1 | |||
| 10 | 12 | 1800 | 1.22-2.1 | |||
| 12 | 14.4 | 2250 | 1.22-2.1 | |||
| 15 | 18 | 2700 | 1.22-2.1 | |||
| Technical Parameters | ||||||
| Impact strength | Transparency | Specific grevity | Coefficient of thermal expansion | Service temperature | Heat conductivity | |
| 35j/m | 72%-90% | 1200kg/m³ | 0.065mm/m°C | -40°C—120°C | 0.21w/m²°C | |
| Tensile strength | Flexural strength | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break | |
| ≥60N/mm | 100N/mm² | 2400Mpa | 28 decibel decrease for 3mm solid sheet | |||
| packaging | Both sides with PE film, the end with paper tape, logo on the pe film. Other package are available based on customers' requirement. | |||||
| delivery | 7-10 days after receipt of deposit. | |||||
| capacity for 20 GP | 1.1mm: 12878m² | 6mm: 2361m² | ||||
| 2mm: 7083m² | 8mm: 1770m² | |||||
| 3mm: 4722m² | 10mm: 1416m² | |||||
| 4mm: 3541m² | 12mm: 1180m² | |||||
| 5mm: 2833m² | 15mm: 944m² | |||||
| capacity for 40GP | 1.1mm: 16666m² | 6mm: 3055m² | ||||
| 2mm: 9166m² | 8mm: 2291m² | |||||
| 3mm: 6111m² | 10mm: 1833m² | |||||
| 4mm: 4583m² | 12mm: 1527m² | |||||
| 5mm: 3666m² | 15mm: 1222m² | |||||
| capacity for 40HQ | 1.1mm: 21212m² | 6mm: 3888m² | ||||
| 2mm: 11666m² | 8mm: 2916m² | |||||
| 3mm: 7777m² | 10mm: 2333m² | |||||
| 4mm: 5833m² | 12mm: 1944m² | |||||
| 5mm: 4666m² | 15mm: 1555m² | |||||
| Brief introduction | ||||||
| A. Product Range | ||||||
| 1).Twin-walls polycarbonate sheet thickness: 4,6,8,10,12 Width: 2100mm. | ||||||
| 2).Triple-walls polycarbonate sheet thickness: 8,10,12,14,16. Width: 2100mm. | ||||||
| 3).Four-walls polycarbonate sheet thickness: 8,10,12,14,16,18,20mm. Width: 2100mm. | ||||||
| 4).Honeycomb polycarbonate sheet thickness: 6,8,10,12,14mm. Width: 2100mm. | ||||||
| 5).X-structure polycarbonate sheet thickness: 14,16,18,20,25,30mm. | ||||||
| 6).Solid polycarbonate sheet [Compact] thickness:0.9-8.0mm. | ||||||
| Width: 1220,1560,1820,2100mm.Usually 1220*2440mm, 2050*3000mm | ||||||
| 7).Corrugated polycarbonate sheet: 0.8-2.5mm. Width is different. | ||||||
B.Length: No limit(Recommend 5800, 6000, 11800,12000mm to suit 20'container &40'container). | ||||||
C.Color: clear/transparent, lake blue, green, blue, opal, white, brown/bronze, silvery gray, red, yellow, etc. | ||||||
Comprehensive presentation
4.Application
5.Main Products
6.Our Advantages
1.Good light transmission
2.Light weight and impact resistance
3.Sound insulation and Flame retardant
4.Excellent energy saving effect
5.Weather resistance(anti-fog/drop)
6.10 years of quality assurance
7.Product Line
8.Company Show
9.Packaging & Shipment
Delivery time
Generally 15 working days after the order confirmed
Packaging
1) Custom package request is appreciate.
2) Standard package: Both Sides Covered With PE Film
10.FAQ
1. Are you manufacturer or Trade Company?
We are professional factory, founded in 1996.OEM is acceptable
2. What's the order process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Customization--- We offers ultimate customization and personalized solutions.
d. Sample ---Standard sample of our factory.
e. Payment terms--- T/T 30% in advanced, balanced before shipment.
f. Production---mass production
g. Shipping--- by sea, air or courier. Detailed picture of package will be provided.
3. What terms of payment you use?
T/T, PayPal, Western Union
4. Do you have any instant chat tool?
E-mail: hzsn(at)hzsn.com.cn
