CHINA manufacturer Magnetic Limit Switch Chl 5220

Share on:

Price:RUB 319.82
Price in USD:Details


Product Overview


Product Description


  • Metallic bottom shell
  • Built-in contact stand has double-spring,so it has long mechanical life
  • Strong electric property 10A,250V,for 500,000 times
Model CHL 5000 5030 5050 5100 5200
Operating force OF(Max.) 750g-cm 750g-cm 750g-cm 750g-cm 900g-cm
Release force RF(Min.) 100g-cm 100g-cm 100g-cm 200g 200g
Pre-travel PT(Max.) 20° 20° 20° 1.8mm 1.8mm
Tripping position TP±10% 22.5° 22.5° 22.5° 2.0mm 2.0mm
Movement differential MD(Max.) 10° 10° 10° 1.2mm 1.2mm
Over travel OT(Min.) 75° 75° 75° 4.0mm 4.0mm
Total travel TT(Min) 95° 95° 95° 5.8mm 5.8mm
Model CHL 5220 5300 5330 5381 5391
Operating force OF(Max.) 900g-cm 150g 150g 150g 550g-cm
Release force RF(Min.) 200g 30g 30g 30g 100g-cm
Pre-travel PT(Max.) 1.8mm 30mm 30mm 30mm 20°
Tripping position TP±10% 2.0mm 22.5° 22.5° 22.5° 22.5°
Movement differential MD(Max.) 1.2mm 14° 14° 14° 14°
Over travel OT(Min.) 4.0mm 20mm 20mm 20mm 75°
Total travel TT(Min) 5.8mm 50mm 50mm 50mm 95°



Our Services


1. Your inquiry will be replied within 24 hours.

2. We offer you professional service in fluent English.

3. Keep the mass production as the sample in high quality

4. Freight forwarder: faster,safer, and convenient.

5. Quality: we have QC on each process,provide high quality products.

Company Information

Company Profile2.jpg


Q: Is sample available and free?
A: Sample is available , but express fee should be paied in advance.
Q: What cerficated do you got ?
A:We got CE , CCC , ISO...
Q: What's your warranty ?
A:Our warranty of the product is 1 years.
Q: What's the delivery time ?
A:Delivery time is depended on quantity . We will delivery as soon as possible.
Q: How about the transport ?
A:We usually transport by Express for samll order , transport by sea or by air for huge quantity.
