100v 240v 50Hz 60Hz EN60601 medical power supply 5V 9V 12V 18V 36V 24V 1A medical power adapter

Modle NO

 EM1024

OUTPUT

SAFETY MODEL NO.

DC VOLTAGE                       Note.2

24V

RATED CURRENT

1.2A

CURRENT RANGE

0-4A

RATED POWER (max.)

16~36W

RIPPLE & NOISE (max.)     Note.3

100mVp-p

VOLTAGE TOLERANCE    Note.4

±5.0%

LINE REGULATIO Note.5

±0.5%

LOAD REGULATION          Note.6

±5.0%

SETUP, RISE, HOLD UP TIME

1000ms, 50ms, 12ms at full load

INPUT

VOLTAGE RANGE

100~ 240VAC

FREQUENCY RANGE

50 ~ 60Hz

EFFICIENCY (Typ.)

77%

AC CURRENT

2A / 100VAC

INRUSH CURRENT (max.)

120A / 230VAC

LEAKAGE CURRENT (max.)

Touch current < 50µA/264VAC

PROTECTION

OVER LOAD

105% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed

OVER VOLTAGE

110 ~ 140% rated output voltage

OVER VOLTAGE

Protection type: Clamp by zener diode

OVER TEMPERATURE

Shut down o/p voltage, re-power on to recover

  ENVIRONMENT

WORKING TEMP.

0~+40 °C (Refer to "Derating Curve")

WORKING HUMIDITY

5~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-20 ~ +85°C , 10 ~ 95% RH

TEMP. COEFFICIENT

±0.04%/°C (0 ~ 40°C)

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC (Note. 6)

SAFETY STANDARDS

IEC60950-1, CB 60601 CE,FCC TUV EN60601-1, EN60601-1-2 approved

WITHSTAND VOLTAGE

I/P-O/P: 5656VDC

ISOLATION RESISTANCE

I/P-O/P: 100M Ohms / 500VDC / 25°C / 70% RH

EMC EMISSION

Compliance to EN55011, EN61000-3-2,3

EMC IMMUNITY

Compliance to EN61000-4-2,3,4,5,6,8,11, EN60601-1-2 medical level, criteria A

OTHERS

MTBF

500K hrs min. MIL-HDBK-217F(25°C)

DIMENSION

137*59*34MM(L*W*H)

PACKING

450g: 80pcs / 36Kg / CARTON

CONNECTOR

PLUG

Standard type P1J: 2.1ψ* 5.5ψ* 11mm, turning fork type center positive for stock ; Other type available by customer requested

CABLE

1.2m 1.5m 1.8m ; Other type available by customer requested

NOTE

1. All parameters are specified at 230VAC input, rated load, 25°C 70% RH ambient.
2. DC voltage: The output voltage set at point measure by plug terminal & 50% load.
3. Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
4. Tolerance: includes set up tolerance, line regulation, load regulation.
5. Line regulation is measured from low line to high line at rated load.
6. Load regulation is measured from 0% to 100% rated load
7. The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the  EMC directives.
