BNC UTP Cat5/5e/6 BNC Video Balun Transceiver Adapter Transmitter for HD 720P 1080P

Product Overview

Description

BNC UTP Cat5/5e/6 Video Balun Transceiver Adapter Transmitter for HD 720P 1080P AHD CVI TVI Camera 200M CCTV A7

Features:

Compatible with all HD-CVI, HD-TVI, HD-AHD

Up to 250m for 720P CVI camera

Up to 150m for 1080P CVI camera

Up to 150m for 720P/1080P TVI camera

Up to 120m for 720P AHD camera

NTSC, PAL video formats

No power required

60dB cross talk and noise immunity

Compact size and easy installation

Built-in transient suppression protection



Technical Specification:

Frequency response: DC to 60Mhz

Attenuation: 0.5dB type

CMRR: 60dB

Surge protection: 4KV

EDS:8KV

Connectors: Male BNC and "Press -fit "terminal blocks

Impedance BNC: 75 OHMs

Terminal: 100 OHMs

Working temperature:-10~+70 Degree

Storage temperature:-30~+70 Degree

Humidity: 0~95 %

Dimension: 39 x 16 x 19mm (excluding connectors)

Material: ABS plastic



PRODUCT NAME	VIDEO BALUN
Specification:	According to the costomer requests
Certification:	CE,ROHS
Delivery:	The stock goods will be delivered within 3days,and the customized goods will be delivered within 1~3 weeks as soon as we received the payment.
Sample:	Free
MOQ:	The MOQ of most products is 1000 pcs, if we have stock for the item, we can sell you them without MOQ.
Terms of trade:	EXW,FOB,CIF,CPT ect
Payment Terms:	T/T in advance,Western Union,Paypal,L/C etc.If the amount more than 5000USD,we can do 30% T/T deposit,70%T/T balance one week before shipment after receiving cargo photoes.
Application:	Widely used in telecommunication equpment,computer,controllers,alarm security,appliance instuments and fields
Serivce:	ODM/OEM
Other service:	CO,CCPIT
