8 портов промышленный M12 IP67 Водонепроницаемый poe коммутатор ethernet коммутатор

8ports industrial M12 waterproof poe switch ethernet switch

TheIWS-1908F2-M12 is a high performance L2+ Managed Ethernet Switch with 8 x10/100/1000TX M12 Copper ports with8PoE and2x1000FX LC Fiber Ports,whichmeets the high reliability requirements demanded by industrial rolling stock applications. It provides L2 wire speed and advanced security function for network aggregation deployment. It delivers enhanced ring recovery less than 20ms in single ring.The IWS-1908F2-M12 is designed to meet witch critical network environment with IP67 aluminum enclosure and M12 connectors for water proof. It is best for railway in train/track side, vehicle and mining applications. For more usage flexibilities, IWS1908F2-M12 supports wide operating temperature from -40~75℃.

•Conformsto IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE802.3af, IEEE802.3at
• Provide 8 10/100/1000TX M12 Copper ports with 8 PoE and 2x1000FX LC Fiber ports, PoE Budget 120W

• High back-plane bandwidth 20Gbps
• Support standard IP/ Extend IP / MAC IP /ARPACL
•  IGMP snooping and IGMP Query mode for Multi-media application
•  Port mirror and bandwidth control
•  IEEE802.3x Flow control
• Support Port Based VLAN / 802 .1Q Tag VLAN
•  Support IEEE802.3ad Port trunk with LACP
•  Support Spanning tree protocol IEEE 802.1d
•  Support IEEE 802.1p class of service
• Support IEEE 802.1x user authentication
•  Support Broadcast storm filter

 • Support DHCP server and client

 • Support System event log

• Support command line interface management

• Management by Web/SNMP/Telnet/Console

• Surge protection for power port and data ports

• Wide power input: 44~57VDC

•  Wide working temperature: -40~75℃

•  IP67Aluminum case

• 200,000 hours MTBF (Parts count reliability prediction)
