X6323A Metal Chip conventional Milling machine vertical universal bench manual mills fresadora fresatrice MACHINERY for sale
- Category: >>>
- Supplier: Shenzhen Integrity Industry Co. Ltd.
Share on (62111494152):
Product Overview
Description
PRODUCT DESCRIPTION
MODEL | X6323A | ||
Table size | 230*1067(9*42) | ||
Long travel(mm) | 670 | ||
Cross travel(mm) | 310 | ||
Vertical travel(mm) | 390 | ||
T-slot No.and size(mm) | 3*16 | ||
Ram travel(mm) | 312 | ||
Distance from spindle nose to table surface(mm) | 0-415 | ||
Spindle hole taper | Standard:R8 | ||
Optional:ISO30/ISO40 | |||
Spindle travel(mm) | 127 | ||
Spindle speed(r.p.m) | standard: Steps 16: 50HZ65-4500,60HZ80-5440 | ||
optional:variable:65-4500 | |||
Auto.quill feed | Three steps:0.04/0.08/0.15mm/revolution | ||
Spindle motor | 2.25kw/3hp | ||
Head swivel | 90° | ||
Head tilting | 45° | ||
Dimension of package | One miller per case | 1400*1476*2030 | |
Two miller per case | 1450*1570*2080 | ||
Three miller per case | 1450*2180*2080 | ||
G.W/set | 1100 | ||
RECOMMENDED PRODUCT
COUPONS
Q1:How long guarantee period you offer?/ how is warranty?
A1:12 month guarantee after machine on board.
Q2: What services are available during the guarantee period?
A2: Free replacing parts available in the warranty period.cost-value replacing parts available beyond thewarranty period.Quick action and reply for the technical questions at any time.
Q3: Can you provide training for operation CNC machines?
A3: Yes, free training in our factory or engineer overseas service available as customerrequirements(relative cost born by customer.
Q4: Can you provide customized machine or Special purpose machine?
A4: Yes, we provide different kinds processing solutions for customers, in order to meet differentrequirements.
Q5: Can we visit your factory before order?
A5: Sure, we warmly welcome you to visit our factory at any time. The more you know us, the more youtrust us! So you can rest assured on our quality products and our best services.
Q6: Where is your factory located?
A6:Our factory is located in Kunming city, Yunnan province, in the southwest of China.
A1:12 month guarantee after machine on board.
Q2: What services are available during the guarantee period?
A2: Free replacing parts available in the warranty period.cost-value replacing parts available beyond thewarranty period.Quick action and reply for the technical questions at any time.
Q3: Can you provide training for operation CNC machines?
A3: Yes, free training in our factory or engineer overseas service available as customerrequirements(relative cost born by customer.
Q4: Can you provide customized machine or Special purpose machine?
A4: Yes, we provide different kinds processing solutions for customers, in order to meet differentrequirements.
Q5: Can we visit your factory before order?
A5: Sure, we warmly welcome you to visit our factory at any time. The more you know us, the more youtrust us! So you can rest assured on our quality products and our best services.
Q6: Where is your factory located?
A6:Our factory is located in Kunming city, Yunnan province, in the southwest of China.
