CIP4 Hydraulic Computerized Guillotine Paper Trimmer Machine Paper Cutter
- Category: >>>
- Supplier: Shanghai Asianray Industry Development Co. Ltd.
Share on (62114280533):
Product Overview
Description
Product Description
78/92/115/130/137/186/220 K
About:
It equipped with AC digital servo controlling technology and10inches colorful touching screen, the data resolution rate is 0.01mm, has self-diagnosticfunction of troubles and displays the operating pattern, 100 program units,over 10000 different cutting positions, it can memorize, store and dynamicfollow-up. The max paper-pushing speed is 5-15m/min. It adopts Japanese hydraulic components, France, Japan and Korea electric components. Taiwan ball lead screw and linear double guide-rail. PLC control system for electric configuration. Its key parts adopt imported bearing of lowmaintenance.IR rayprotective device is more convenient for cutting with optical knife-line alignment,button operated by two hands, singlcirculation cutting device ect.
Technical parameters:
Model / Specifications | 78 | 92 | 115 | 130 | 137 | 186 | 220 |
Cutting width(cm) | 78 | 92 | 115 | 130 | 137 | 186 | 220 |
Max.cutting height without assistance pressing plate(cm) | 13 | 13 | 16.5 | 13 | 16.5 | 16.5 | 16.5 |
Max.cutting depth(cm) | 78 | 93 | 115 | 130 | 145 | 200 | 220 |
Min cutting depth without assistance pressing plate(cm) | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 |
Extended length of working table(cm) | 64 | 65 | 73 | 73 | 74 | 75 | 75 |
Height of working table(cm) | 86.5 | 86 | 89 | 86.5 | 89-92 | 89-92 | 89-92 |
Machine width including side working table(cm) | 215 | 233 | 266 | 266 | 287 | 342 | 376 |
Total length of working table(cm) | 178 | 198 | 226 | 241 | 259 | 327 | 355 |
Cutting speed(r/min) | 45 | 45 | 45 | 45 | 45 | 40 | 33 |
Max. Paper pressure(n) | 30000 | 35000 | 40000 | 40000 | 45000 | 65000 | 70000 |
Power of main motor(kw) | 3 | 3 | 4 | 4 | 4 | 7.5 | 7.5 |
Machine weight(kg) | 2500 | 2700 | 4000 | 3900 | 4500 | 7000 | 10200 |
Overall dimension(cm) | 210x140 x195 | 225x140 x195 | 255x160 x215 | 260x153 x195 | 280x160 x215 | 340*182* 230 | 390*190 *270 |
