Full Automatic Tunnel Car Wash Machine For Fast Washing CE
- Category: >>>
- Supplier: Zouping Jinding Coating Equipment Co. Ltd.
Share on (62115828124):
Product Overview
Description
Product Description
| Item | Model | JD-T9 | JD-T7 | JD-T5 |
| Size | Machine size | 11000*3800*3100mm | 9500*3800*3100mm | 3650*4200*3100mm |
| Floor area | 11700*4000mm | 13400*4000mm | 10500*4000mm | |
| Cost consumption | Total power | 28KW | 27KW | 17KW |
| Maximum operating power | 11.4KW | 11.4KW | 11.4KW | |
| Various components power | Top brush 0.3KW*1 | Top brush 0.3KW*1 | Top brush 0.3KW*1 | |
| Side brush 0.3KW*4 | Side brush 0.3KW*4 | Side brush 0.3KW*2 | ||
| Small brush 0.2KW*4 | Small brush 0.2KW*2 | Small brush 0.2KW*2 | ||
| Conveyor | Conveyor | Conveyor | ||
| Traveling 1.1KW*1 | Traveling 1.1KW*1 | Traveling 1.1KW*1 | ||
| Water pump 0.75KW*1 | Water pump 0.75KW*1 | Water pump 0.75KW*1 | ||
| Dryer 5.5KW*2 | Dryer 5.5KW*2 | Dryer 5.5KW*2 | ||
| High pressure | High pressure | High pressure | ||
| pump 4KW*1 | pump 4KW*1 | pump 4KW*1 | ||
| Swing motor | Swing motor | Swing motor | ||
| 0.025KW*3 | 0.025KW*3 | 0.025KW*3 | ||
| Water consumption | 125L | 125L | 100L | |
| Wash | Washable car | Car, jeep, coach below 9seats | Car, jeep, coach below 9seats | Car, jeep, coach below 9seats |
| Liquid using | shampoo | shampoo | shampoo | |
| wax | wax | wax | ||
| Washing time | 60sets/hour | 50sets/hour | 20sets/hour |
1.Scope of application
Car washing machine apply to clean, wax and dry the cars,jeeps,SUV,mini van and other box-type vehicles whose height is less than or equal 2m.
2.Car washing machine detailed list
A. Car washing machine B.Host support structure C.Mobile host system
D.Rotating high-pressure flushing system E.Lotion spray system F. Foam pourer system
3.Specification
a.Cleaning vehicle maximum size shape
b.Wash the car site installation size requirements
c.High-pressure flushing water consumption in a week
Foundation base,source of water,power supply,air source(air compressor)are all supplied by users to the designated spot of drawing(foundation drawing provided by manufacturer).
4.Product feature
Easy operation,easy to use,Function of flexible and varied,high automation level,good-looking appearance,energy conservation and environment protection,long service life, Wash the car costs low,Low maintenance cost,Antirust performance is good,good reliability.
5.Cleaning way
cleaning ways According to the set sequence can be choosed of free combination on the touch screen.
Detailed Images
FAQ
Q: What's you car washing machine advantages ?
A: JD insist do China high end quality car wash machine for over 10 years, machine use 8 years won't be a problem. Lower rate of fault, high stability, famous brand components, rich experience, brand, precious craft all is the features of machine.
Q: Who will install our car washing machine?
A: We will dispatch 2 rich experience engineers to your site to give instructions of installaing and traing work, but client will need handle the round ticket, visa cost, local accommodation, and allowance $50 per engineer per day. 7-10 days finished project.
Q: What is your terms of payment ? and what's the delivery time?
A: 30% TT in advance, 70% before shipment.
L/C at sight negotiable.
45-50 days after we received the down payment.
Q: What is the warranty of your car washing machine?
A: The equipment warranty become effective when you receive the machines, and the warranty period is 3 years. We provide spare parts to maintain the machine life-long and client need to pay the cost after warranty period.
