KD 1083 Android 10 built in DSP make voice better Three way calling NXP6686 radio android car audio for IX35 and for TUCSON 2015
- Category: Car Video >>>
- Supplier: Shenzhen Klyde Electronics Co. Ltd.
Share on (62120066511):
Product Overview
Description
System and Hardware Parameters | ||||||
OS | Android 10.0 System | TFT drive IC | Rockchip PX5-3 | |||
CPU | Rockchip PX5-3 ,Cortex-A53, Octa core | Loader | SHINNY D-28HX-PWW-53X | |||
RAM | SAMSUNG DDR3 4GB | Pick up | HITACHI 1200HX | |||
Flansh | 64GB | Motor drive | MABUCHI | |||
Radio | NXP 6686 | Amplifer IC | TDA 7851 | |||
GPS | SIRF III | DVD decoder IC | Sunplus 8202VGQ | |||
Screen | Capacitive and multi-touch screen | Screen | Hanstar Screen | |||
Video Decoder | 1080P HW | Power supply | 4*50W | |||
WIFI | Built in | Bluetooth | IVT | |||
DVR | USB Camera (PC Standard) | |||||
Multi-media Parameters | Radio Parameters | |||||
Music Format | MP3,WMA,AAC,RM,LFAC etc | Frenqency Range | FM:76.0MHz-108.0MHz | |||
Video Format | MPEG-1/2/4,H264,H263,VC1,RV,RMVB,DivX,Sorenson SparK,Spark,VP8,AVS Stream... | Frenqency Range | AM: 522KHz-1620KHz | |||
Picture Format | JPG/BMP/JEPG/GIF/PNG | Country | China,Europe,Eastern,Europe,Russia,USA1,USA2,Japan | |||
DVD Parameters | Amplifer Parameters | |||||
Vidio output range | 1.0V-1.2V(75Ω) | Test Voltage | 13.8V | |||
Compatible Disc | DVD/DIVX/MP4/MP3/MP2/VCD | Max output power | 4*50W | |||
New function:Bulit in Apple Carplay (Optional Function)
CarPlay is a smarter, safer way to use your iPhone in the car. CarPlay takes the things you want to do with your iPhone while driving and puts them right on your car`s built-in display. You can get directions, make calls, send and receive messages, and listen to music, all in a way that allows you to stay focused on the road. Just connect your iPhone and go.
Carplay video: https://www.youtube.com/watch?v=CUa67RCdlq0&t=19s
Split Screen
Split 1024*600 touch dual screen run 2 apps at the same time side by side
New function:DSP
DAB+(optional)
Digital Audio Broadcasting allows you multi-regional music with your local well-known and also new channels. CD sound quality and noise-free in excellent transmission make DAB Radio a special experience in the vehicle. Permanent increase in channels and expansion of the station area soon make DAB accessible to most of Europe.
Working Voltage:5V
Operating Temperature Range: -20 to 70
Storage Temperature Range : -40 to 80
Signal to Noise RF=72dBM : Mini 50dB
Distortion at Ref out RF=72dBM : Mini 1%
Channel Separation RF=-72dBM at 1KHZ :Mini 50dB
TMPS(optional)
This system contains a monitor and four sensors , when you use the internal sensors , sensor instead of the original car gas nozzle installed , use the external sensor , sensor use anti-theft nut directly fixed in the original car gas nozzle; sensor measuring tire pressure and temperature, and send the information of tire to TPMS receiver, the receiver send the date to DVD by USB port . when the tire pressure is low , or leak , and high temperature , DVD have a warring through sound and light, so as to remind drivers to pay attention to vehicle safety.k.
PARROT BLUETOOTH(optional)
Telephony
Internet access (through DUN or PAN)
Audio Streaming
Voice Recognition / Text To
Speech
The FC6000T integrates the latest version of the Parrot Bluetooth stack (Blues).
Blues gives to the customer a very high level of compatibility with most of the phones available on the market and provide phonebook and list
synchronization. FC6000T offers the possibility to use a Speaker Independent Voice Recognition (SIVR) and a Text To Speech algorithm (TTS).
REAR VIEW CAMERA(optional)
Established in 2009,Shenzhen Klyde Electronics Co.,Ltd. is a professional high-tech enterprise specialized in developing,manufacturing and selling car audio and car video product.Our products including high-tech car multimedia system with 9 years experience manufacturer in car entertainment field.Our products included Mitsubishi Android Car Dvd/Opel Android Car Dvd/Chinese Series Android Car DVD/Chevrolet Android Car Dvd/Chrysler /Jeep Android Car Dvd/Gmc Android Car Dvd/Ford Android Car Dvd/Ssangyong Android Car Dvd and so on.
Q1: Will It Fit My Car?
A1: Please send us The Year/Name and Dashboard picture Which You Are Looking For.
Q2:How Long Is The Warranty?
A2:One Year.
Q3:Why The Remote Couldn't Work?
A3:Please Check The Battery Is It Out Of Power
If you have any questions,please contact me.
