3 Way Diverter Valves Used For Pneumatic Conveying Pipie Line
1.Pneumatic cock shunt valve uses air pressure as the power driving source.
2.Through the reciprocating action of the cylinder, the reciprocating motion of the rack fixed at the end of the piston rod is driven, and the gear meshed with it converts the linear operation into the rotary motion of the valve core to realize the valve core.
3.The only channel and the different channels of the valve body are connected and disconnected, so that the materials are discharged according to different preset routes.
1.Double way valve is widely used in building materials, metallurgy, mining, petrochemical, electric power, light industry and other industries,.
2.Used for high-pressure pneumatic conveying cement, cement raw materials, limestone, coal powder and other powdery material pipeline system,.
3.The role of transport commutation, generally installed in the branch of the pipeline.
1.Plug Diverters are heavy-duty alternatives to the flap type conveying diverter.
2.They have an internal plug that rotates 150 degrees to reroute product from one leg to the other. The round hole in the plug matches the round blow through ports, making for a very smooth transition.
3.The units work well on applications with large particles that may get caught in a flap type diverter, causing leakage to the dead leg.
4.As there is no rubber seal, the plug diverter is well suited to more abrasive products.
5.A pneumatic rotary actuator is used to rotate the plug as standard, but can also be supplied with an electric actuator or hand crank.
6.The units come standard with spigots as specified by the customer: flangd, OD tube or nominal pipe.
7.Sizes available are: 2, 3, 4, 5, 6, 8 and 10 inch.
8.Work pressure (MPa) medium temperature (℃) for 0.05 200 or less pulverized coal, raw materials,.
8.Such as cement works: powder and granular materials delivery valve is mainly composed of left and right body, rotary valve tray, adjusting device, sealing surface and locating the CAM and other parts.
Output(capacity) calculation: G=0.06VnKp(t/h)
( V= Volume , N=rotating speed (r/min) , P=volumetric weight, K=full coefficient)
Note: Granule size:0.6-0.8; powder is 0.4-0.6(working pressure 25-100KPa
(1) 1. The production capacity increases with the increase of the impeller speed within a certain range.
2. After exceeding the critical speed, it will decrease correspondingly with the increase of the impeller speed.
(2) 1. The abrasion increases with the increase of impeller speed.
2.The higher the sspeed, the greater the abrasion.
More stroke housing structure, improve maintenance and maintenance performance. The improved generation III only needs to remove the stroke cover to complete the valve core folding and adjustment work..
Sichuan Ziyang Self-reliance Grain Oil Machinery Co., LTD. specializes in designing, manufacturing, and distributing high-quality Rotary Airlock valves used in pneumatic conveying systems for application in bulk solids handling in the Plastics, Chemical, Food, Pharmaceutical and Detergent industries, since 1957, located in Ziyang city, Sichuan province, China.
Long-term supplied to Buhler China and COFCO, our Rotary Airlock valves achieved more than 70% market in same products in China.
At the same time, our TXFLF series Plug Diverter praised by users also.
Please contact us with all of your bulk material handling applications, and let us put our expertise to work for you.
