Promotional great oil drilling rig bit auger for earth
- Category: Earth Augers >>>
- Supplier: Shanghai Vostosun Industrial Co. Ltd. [Shanghai China]Shanghai
Share on (62121878664):
Product Overview
Description
Promotional great oil drilling rig bit auger for earth
Application
Key Specifications/Special Features:
Product feature and advantages
Adjustable cutting arms can meet the specific requirements of different reaming diameters;
After reaming the bore hole, convey spoil with drilling bucket or cleaning bucket;
Cutting arms are easy to spread and retract, box-type structure is easy to maintenance;
Applicable layers: Hard stratum, frozen soil and medium soft rock.
To be designed as requested:
Cutting diameter
Key components reinforce
Swing number
Kelly box
Limit hold number
Adjustable cutting arms can meet the specific requirements of different reaming diameters;
After reaming the bore hole, convey spoil with drilling bucket or cleaning bucket;
Cutting arms are easy to spread and retract, box-type structure is easy to maintenance;
Applicable layers: Hard stratum, frozen soil and medium soft rock.
To be designed as requested:
Cutting diameter
Key components reinforce
Swing number
Kelly box
Limit hold number
| Diameter | Tool height | Swing no. | Limit hole no. | Teeth quantity | Reaming multiples | Weight |
| 600-1200 | 3050 | 2 | 2 | 28 | 1.5-2.0 | 1190 |
| 800-1600 | 3100 | 2 | 3 | 28 | 1.5-2.0 | 1310 |
| 900-1800 | 3050 | 2 | 3 | 28 | 1.5-2.0 | 1500 |
| 1000-2000 | 3050 | 2 | 3 | 30 | 1.5-2.0 | 1650 |
| 1100-2200 | 3050 | 2 | 4 | 30 | 1.5-2.0 | 1880 |
| 1200-2400 | 3050 | 2 | 4 | 30 | 1.5-2.0 | 2350 |
| 1500-3000 | 4000 | 2 | 4 | 32 | 1.5-2.0 | 3600 |
Gold-Ti driling buckets Production:
GoldTi drilling rigs and drilling buckets at site:
Some parts and accessoires available for different drilling rigs:
Production Type
