Price:RUB 113,727.00 - RUB 227,454.00
Price in USD:Details

Quantity:


Product Overview

Description

Shenzhen Price Huawei OSN 1500B OSN 3500 OSN 7500 SLQ41 N3SLQ41 SSN3SLQ41 SLH41 N3SLH41 SSN3SLH41

Products Related

OSN 3500.jpg

 Huawei Optix OSN 3500



OSN 7500.jpg

Huawei Optix OSN 7500



OSN 7500 II.jpg

Huawei Optix OSN 7500 II



SDH Boards List

S1011326 master
S1011327 cabinet
02112963 SSTB9RACK01 N63E assembled cabinet (2200x600x300mm)
02112964 SSTB9RACK02 N63E assembled cabinet (2000x600x300mm)
02112965 SSTB9RACK03 N66T assembled cabinet (2200x600x600mm)
02112966 SSTB9RACK04 N66T assembled cabinet (2000x600x600mm)
21070321 SSTB0FRAME01 heightening enclosure frame (400)
21070322 SSTB0FRAME02 heightening enclosure frame (400)
S1011328 shelf
02300529 SST1SUBRACK shelf
S1011329 system board
03030DYT SST2UXCSA enhanced cross clock board
03030DJX SST1SXCSA Super cross clock board
03030DKB SST1IXCSA unlimited cross clock board
03039021 SSN2GSCC system control and communication board
03030CEP SSN3GSCC system control and communication board
03020CQV SSN4GSCC system control and communication board
03028245 SST1EOW Orderwire board
03028246 SST1AUX system auxiliary interface board
03028193 SST1PIU Power Interface Board
S1011330 STM-64
03030ESD SSN1SLD64 (I-64.1, LC) 2xSTM-64 (I-64.1, LC)
03030GGW SSN1SLD64 (S-64.2b, LC) 2xSTM-64 (S-64.2b, LC)
03035296 SSN1SF64 (Ue-64.2ce, LC) STM-64 (band FEC) (Ue-64.2c ~ e)
03030KBP SSND0SF64A00 STM-64 (band FEC) (DRZ optical interface pattern)
03037692 SSN1SL64 (I-64.2, LC) STM-64 (I-64.2, LC)
03030BME SSN1SL64 (S-64.2b, LC) STM-64 (S-64.2b, LC)
03030BNT SSN1SL64 (Le-64.2, LC) STM-64 (Le-64.2, LC)
03030CCS SSN1SL64 (Ls-64.2, LC) STM-64 (Ls-64.2, LC)
03030BDK SSN1SL64 (L-64.2b, LC) STM-64 (L-64.2b, LC)
03030BEP SSN1SL64 (V-64.2b, LC) STM-64 (V-64.2b, LC)
S1012166 STM-64 color
03070851 SSN1SL64- (40Km / LC / PIN)
03070548 SSN1SF64- (40Km / LC / PIN)
S1011134 STM-16
03052547 SSND0SLO1610 8 * STM-16 (I-16, LC)
03052548 SSND0SLO1611 8 * STM-16 (S-16.1, LC)
03052549 SSND0SLO1612 8 * STM-16 (L-16.1, LC)
03052550 SSND0SLO1613 8 * STM-16 (L-16.2, LC)
03030BFK SSN1SF16 (Ue-16.2C & D & F, LC) STM-16 (band FEC) (Ue-16.2C & D & F, LC)
03052551 SSN1SLQ16 (I-16, LC) 4 * STM-16 (I-16, LC)
03052552 SSN1SLQ16 (S-16.1, LC) 4 * STM-16 (S-16.1, LC)
03052553 SSN1SLQ16 (L-16.1, LC) 4 * STM-16 (L-16.1, LC)
03052554 SSN1SLQ16 (L-16.2, LC) 4 * STM-16 (L-16.2, LC)
03030EPX SSN3SL16 (L-16.2JE, LC) STM-16 (L-16.2JE, LC)
03030EPY SSN3SL16 (V-16.2Je, LC) STM-16 (V-16.2Je, LC)
03030EQA SSN3SL16 (U-16.2, LC) STM-16 (U-16.2, LC)
03052444 SSN3SL16A (I-16, LC) STM-16 (I-16, LC)
03052445 SSN3SL16A (S-16.1, LC) STM-16 (S-16.1, LC)
03052446 SSN3SL16A (L-16.1, LC) STM-16 (L-16.1, LC)
03052447 SSN3SL16A (L-16.2, LC) STM-16 (L-16.2, LC)
S1012164 STM-16 color
03070956 SSN3SL16- (640Km / LC / APD)
03070230 SSN1SF16- (640Km / LC / APD)
03070957 SSN3SL16- (170Km / LC / APD / 2mW)
S1011135 STM-4
03052468 SSN1SLQ4A (I-4, LC) 4xSTM-4 (I-4, LC)
03052469 SSN1SLQ4A (S-4.1, LC) 4xSTM-4 (S-4.1, LC)
03052470 SSN1SLQ4A (L-4.1, LC) 4xSTM-4 (L-4.1, LC)
03052471 SSN1SLQ4A (L-4.2, LC) 4xSTM-4 (L-4.2, LC)
03052472 SSN1SLQ4A (Ve-4.2, LC) 4xSTM-4 (Ve-4.2, LC)
03052458 SSN1SLD4A (I-4, LC) 2xSTM-4 (I-4, LC)
03052459 SSN1SLD4A (S-4.1, LC) 2xSTM-4 (S-4.1, LC)
03052460 SSN1SLD4A (L-4.1, LC) 2xSTM-4 (L-4.1, LC)
03052461 SSN1SLD4A (L-4.2, LC) 2xSTM-4 (L-4.2, LC)
03052462 SSN1SLD4A (Ve-4.2, LC) 2xSTM-4 (Ve-4.2, LC)
03052448 SSN1SL4A (I-4, LC) STM-4 (I-4, LC)
03052449 SSN1SL4A (S-4.1, LC) STM-4 (S-4.1, LC)
03052450 SSN1SL4A (L-4.1, LC) STM-4 (L-4.1, LC)
03052451 SSN1SL4A (L-4.2, LC) STM-4 (L-4.2, LC)
03052452 SSN1SL4A (Ve-4.2, LC) STM-4 (Ve-4.2, LC)
S1011136 STM-1
03052312 SSN1SLT1 (S-1.1, LC) 12xSTM-1 (S-1.1, LC)
03051338 SSN2SLO1 (I-1, LC) 8xSTM-1 (I-1, LC)
03051334 SSN2SLO1 (S-1.1, LC) 8xSTM-1 (S-1.1, LC)
03051335 SSN2SLO1 (L-1.1, LC) 8xSTM-1 (L-1.1, LC)
03051336 SSN2SLO1 (L-1.2, LC) 8xSTM-1 (L-1.2, LC)
03051337 SSN2SLO1 (Ve-1.2, LC) 8xSTM-1 (Ve-1.2, LC)
03052681 SSN1SLQ1A (Ie-1, LC, MM) 4xSTM-1 (Ie-1, LC, multimode)
03052473 SSN1SLQ1A (I-1, LC) 4xSTM-1 (I-1, LC)
03052474 SSN1SLQ1A (S-1.1, LC) 4xSTM-1 (S-1.1, LC)
03052475 SSN1SLQ1A (L-1.1, LC) 4xSTM-1 (L-1.1, LC)
03052476 SSN1SLQ1A (L-1.2, LC) 4xSTM-1 (L-1.2, LC)
03052477 SSN1SLQ1A (Ve-1.2, LC) 4xSTM-1 (Ve-1.2, LC)
03052453 SSN1SL1A (I-1, LC) STM-1 (I-1, LC)
03052454 SSN1SL1A (S-1.1, LC) STM-1 (S-1.1, LC)
03052455 SSN1SL1A (L-1.1, LC) STM-1 (L-1.1, LC)
03052456 SSN1SL1A (L-1.2, LC) STM-1 (L-1.2, LC)
03052457 SSN1SL1A (Ve-1.2, LC) STM-1 (Ve-1.2, LC)
S1011137 STM-1
03037391 SSN1SEP1 8xSTM-1 Line Features
03020EHW SSN1SLH1 16xSTM-1 line function -1x1 puzzle



Please click here to browse more related Huawei SDH Equipments and Boards.

Product Description



Functions and Features

The SLQ41 transmits and receives STM-1 or STM-4 optical signals, performs O/E conversion for the STM-1 or STM-4 optical signals, extracts and inserts overhead bytes, and generates alarm signals on the line.

Table 1 provides the functions and features of the SLQ41.

Table 1 Functions and features of the SLQ41
Function and Feature Description
Basic functions Transmits and receives 4xSTM-1 or 4xSTM-4 optical signals.
Specifications of the optical interface
The STM-1 optical module or STM-4 optical module can be used.
  • When the STM-1 optical module is used, the SLQ41 supports different types of standard optical interfaces, namely, the I-1, S-1.1, L-1.1, L-1.2, and Ve-1.2. The characteristics of the optical interfaces of the I-1, S-1.1, L-1.1, and L-1.2 types comply with ITU-T G.957. The characteristics of the optical interface of the Ve-1.2 type comply with the standards defined by Huawei.
  • When the STM-4 optical module is used, the SLQ41 supports different types of standard optical interfaces, namely, the I-4, S-4.1, L-4.1, L-4.2, and Ve-4.2. The characteristics of the optical interfaces of the I-4, S-4.1, L-4.1, and L-4.2 types comply with ITU-T G.957. The characteristics of the optical interface of the Ve-4.2 type comply with the standards defined by Huawei.

Supports the CWDM and DWDM colored optical interfaces. The optical interface uses the LC connector. The CWDM optical interface supports the transmission distance of 80 km, and the DWDM optical interface supports the transmission distance of 120 km.
Specifications of the optical module
  • Supports the detection and query of the information about the optical module.
  • Supports the usage and detection of the SFP optical module, which facilitates the maintenance and upgrading of the optical module.
  • Provides the ALS function. The optical interface supports the setting of the on/off state of a laser.
  • The SLQ41 supports the single-fiber bidirectional optical module, and the single-fiber bidirectional optical module does not support loopbacks at the optical interface by using fiber jumpers.
Service processing
  • When the STM-1 optical module is used, the SLQ41 supports the VC-12 services, VC-3 services, and VC-4 services.
  • When the STM-4 optical module is used, the SLQ41 supports the VC-12 services, VC-3 services, VC-4 services, and VC-4-4c concatenation services.
Overhead processing
  • Processes the section overheads of the STM-1 signals or STM-4 signals.
  • Supports the transparent transmission and termination of the path overheads.
  • Supports the setting and query of the J0, J1, and C2 bytes.
  • Supports one to four channels of ECC communication.
Alarms and performance events Reports various alarms and performance events, which facilitates the management and maintenance of the equipment.
Protection schemes
Maintenance features
  • Supports inloops and outloops at optical interfaces.
  • Supports inloops and outloops on VC-4 paths.
  • Supports warm resets and cold resets. The warm reset does not affect services.
  • Supports the query of the manufacturing information of the board.
  • Supports the in-service loading of the FPGA.
  • Supports the upgrade of the board software without affecting services.
  • Supports the PRBS function. For details, see Availability.
  • Supports the press-to-collect function in fault data collection.
  • Hot board swapping.
